  6. Q & As
?     Asked on 7/18/2015 by Lana

I was successfully rebuilding my valve assembly whem I think my old stem crumbled. Is this the right part for Hayward s244t sand filter ? Does the handle levor go through this w/ a steel pin ? Is there a secret to doing that ?
 Reply

A  Answered on 7/23/2015 by InyoPools Product Specialist Lennox H.

Hi Lana, The SP0714T Valve  is the valve that came with your Hayward S244T  Sand Filter. The Key/seal Assembly w/ Glued In Gasket (SPX0714CA) will be the correct part you will need. You can fin other part for this valve via the Hayward Multiport Variflo SP714T Parts List.
 Reply


?     Asked on 4/28/2016 by Christina Ramirez

I need a key and stem assembly only for my SP0710XR50 will this one work with mine.
 Reply

A  Answered on 4/29/2016 by InyoPools Product Specialist Andy O.

Christina- The 4700-09x Key And Stem Assembly (spx0710xc) is the correct part for the SP0710XR50. Please note that this does not come with the 4700-10x  Gasket, Valve Seat - 5 Spoke (spx0710xd).
 Reply


?     Asked on 8/22/2019 by EMaz

My handle wont budge. I can see there is sand (another problem) but it almost attached. Can i remove it? I have looked to replace the whole thing, but the only part # I can find isn't an exact match. SP-710X-B. I have a s200 sand filter.

 Reply

A  Answered on 9/24/2019 by Industry Professional

That valve is very old & replaced complete with a Praher SM1-HP3 ( 26-253-1105 ) new valve comes complete with the plumbing to mate up to your S200 filter.
 Reply
