RUN CAPACITOR, 25 MFD - 628318-307

$33.99

IN STOCK

Part # 5270-08

By U.S. Seal Manufacturing

  5 Average

Details

Top

Part # 5270-08

Manufacturer Code 628318-307

Dimensions 1-3/4" x 3-1/2"

Alternate Part #'s 17586325, 2443, 2511398-007, 35-125-1125, 5VR0253, 628318307, RD25370, SFP37T25H263B

Product Description

Run Capacitor1-3/4"dia x 2-7/8"hgt

Product Specifications

Diameter:
1-3/4 in.
Length:
3-1/2 in.
Top

?     Asked on 4/4/2020 by Carl Kaucky

I need a capacitor for an Haywood pool pump model K48N2N106A1 serial 8B06. 2 1/2 HP. The capacitor is an CSC 325P256H37M30N4X

 Reply

A  Answered on 4/7/2020 by InyoPools Product Specialist Matt S.

your capacitor label shows that it is a 25 MFD run capacitor; RUN CAPACITOR, 25 MFD - 628318-307 is the correct replacement
 Reply


?     Asked on 3/30/2020 by

The old one I am replacing has one pin for each wire. the replacement has 4. Would I connect to any one of them?
 Reply

A  Answered on 3/30/2020 by Industry Professional

yes, you can use any of the tabs
 Reply


?     Asked on 1/27/2020 by Norman Maia

I have a whisperflow pump/motor, the capacitor is not kicking in the high speed, it is a genteq 25 uf +-6% 50/60 HZ 370 VAC, can you let me know what you have as a replacement please? thanks Norm
 Reply

A  Answered on 1/29/2020 by InyoPools Product Specialist Lennox H.

Hi, Norman. This is the correct replacement based on the info provided.
 Reply


?     Asked on 8/1/2019 by Ron

I have a bad capacitor it is a CSC 628308-405. what is the equivalent capacitor to replace it
 Reply

A  Answered on 8/1/2019 by InyoPools Product Specialist Lennox H.

Hi, Ron. Unfortunately, we do not have an equivalent replacement.
 Reply


?     Asked on 6/3/2019 by Mark

will this capacitor replace a capacitor 25 microf +- 6% , 440 vac, 10000 afc and 70 degree C ?
 Reply

A  Answered on 10/2/2019 by Industry Professional

Yes, voltage is irrelevant you are good to go.
 Reply


?     Asked on 1/7/2019 by Jeff Ammerman

What is the correct capacitor for a Pentair WFE-6?
 Reply

A  Answered on 1/7/2019 by InyoPools Product Specialist Hector F.

In order to cross-reference the motor capacitor, we will actually need the motor model, part or catalog number. You can also try and use the guide by clicking here which may assist in locating that.
 Reply


?     Asked on 4/20/2018 by Tommy Somers

I have a century centurion 2.0hp part number 0-159988-06. Is this the correct capacitor?
 Reply

A  Answered on 4/20/2018 by InyoPools Product Specialist Hector F.

The correct capacitor for that motor is the part number 628318-307
 Reply


?     Asked on 4/17/2018 by Todd

Hello, I have a 2hp Century Centurion Pool/Spa motor part 7-159988-06 230 volt. What run capacitor part do you think I need?
 Reply

A  Answered on 4/17/2018 by InyoPools Product Specialist Lennox H.

Hi, Todd. That motor will use the 30 MFD - 370 VAC - 175863-30
 Reply


?     Asked on 2/15/2018 by Doug

I have a motor model #K48K2PA105C1 and need a new run capacitor. It appears that the Titan Pro 370 TRC25 is what I am looking for. Is that correct? Thanks
 Reply

A  Answered on 2/15/2018 by InyoPools Product Specialist Lennox H.

Hi, Doug. Some model uses a 20 MFD 370 VAC Run Capacitor - 17586320 or an 25 MFD 370 VAC Run Capacitor - 17586325
 Reply


?     Asked on 9/17/2017 by tom nelson

i have a flowmaster xp2 model 06020400-2 with emerson motor 155cxblr-968 what capacitor do i need
 Reply

A  Answered on 9/18/2017 by InyoPools Product Specialist Lennox H.

Hi, Tom Nelson. The T55CXBLR-968 motor uses the 50MFD-370VAC Run Capacitor - 628318-313
 Reply


?     Asked on 6/2/2017 by rick

my cap # is 628318-306...is the 628318-306 simply a new and improved replacement cap? thanx
 Reply

A  Answered on 6/3/2017 by InyoPools Product Specialist Patrick P.

The 5270-08 is the newest capacitor and is a replacement for your 628318-306
 Reply


?     Asked on 5/27/2017 by Ross

Hi, I have a Pentair Whisper flow WFE-1 1hp pool pump with a motor from Magnetek part # 01-177450-03. I need a new run capacitor but the current one is so rusted I can't read the part #. Would this be the correct capacitor?
 Reply

A  Answered on 5/27/2017 by InyoPools Product Specialist Hector F.

Your capacitor would be part number 5270-06.
 Reply


?     Asked on 4/25/2017 by Rodney Worthington

i have a pentair whisperflow 2hp 2 speed pump motor that will start in low speed but sometimes it just hums when i try to start it in highspeed, sometimes it starts
 Reply

A  Answered on 4/25/2017 by InyoPools Product Specialist Scott W.

What is the part or model number of your motor so I can provide the correct capacitor for you?
 Reply


?     Asked on 4/24/2017 by Tim

I have a pentair 1hp pump, motor number: 196238/ pump model number: SF-N1-1A/340038. I am unable to find capacitor as it exploded and blew off. This appears to be the correct size in regards to the capacitor cover. Do you know if this is the correct one or if there is a way to find out. Thanks
 Reply

A  Answered on 4/26/2017 by InyoPools Product Specialist Lennox H.

Hi, Tim. You will need the 30MFD 370V Run Capacitor - 5VR0303 based on the current spec we have for that motor.
 Reply


?     Asked on 4/12/2017 by Scott Reda

How can i check to see if my capacitor is bad?
 Reply

A  Answered on 4/12/2017 by InyoPools Product Specialist Stacey M.

Hello Scott, when a capacitor goes bad it hums to test this Use an analog or digital volt meter. Both work in essentially the same way and are both appropriate for the job. Set the meter to 1k ohms to begin the test. Touch the two terminals with your ohms meter test leads. The basic check involves touching the test leads twice and comparing the reaction. Touch the test leads to the terminals and then reverse them.The needle in your meter should swing to 0 ohms and swing back to infinity on an analog meter, and should display open line every time that you reverse on a digital meter. If it does, you've got a live capacitor and your problems are elsewhere. If there is no difference the capacitor is dead.
 Reply


?     Asked on 3/22/2017 by

I need a replacement capacitor for my pump motor. I had a CSC 25UF +/-6% 370VAC/B 50/60HZ . The dimensions are 1.75" diameter and 3" in length. The CSC part number is 325P256H37M30N4X.
 Reply

A  Answered on 3/22/2017 by InyoPools Product Specialist Lennox H.

Hi, This is the correct replacement capacitor based on the specs provided.
 Reply


?     Asked on 1/17/2017 by john gill

I have a genteq 97f9604, 22.5 uf +6, 50/60Hz, 370VAC. Will the above replace my old capacitor?
 Reply

A  Answered on 1/18/2017 by InyoPools Product Specialist Lennox H.

Hi, John. Yes, this capacitor can replace your existing capacitor if it's the same physical size.
 Reply


?     Asked on 1/1/2017 by Ronald

i have a STA-RITE 2 speed pump. The motor is only running on low speed, after checking I found the capacitor is bad and has blown up leaking fluid. The capacitor is a Genteq 25uf 97f9606 50/60Hz 370VAC +6 -6% model #628318-307? I am having trouble locating a replacement that matches all serial numbers. Am I missing something or what part do I need?
 Reply

A  Answered on 1/3/2017 by InyoPools Product Specialist Adam Y.

Good afternoon Ronald, Is the capacitor located on top of the motor or in the back? If it is a silver capacitor located on top then this would be the correct partCapacitor, Run Rd 25-370 (17586325) - 628318-307
 Reply


?     Asked on 10/13/2016 by George C

I have a 2 speed pump motor (Starite Ultimax 1016174) that was running well until the run(?) capacitor "blew out the top" with burning smell. This would be the replacement one, But, it was attached to a relay-looking thing within the cap cover that has some plastic case melting--might still be good, rest of visible wiring looks fine. Do you sell the relay? What does it do? Thanks, GC
 Reply

A  Answered on 10/14/2016 by InyoPools Product Specialist Lennox H.

Hi, George. The replay allows the motor the go from high to low speed, if you provide us with the spec off of the replay we can see if we have that part.
 Reply


?     Asked on 8/28/2016 by Chuck Lansing

Checked my pool yesterday and found that my capacitor had actual blown up. Is this as simple as just replacing it.
 Reply

A  Answered on 8/30/2016 by InyoPools Product Specialist Alan M.

Yes, Replacing a capacitor is quite easy. You will want to correctly identify and purchase a replacement capacitor from the markings on the shell. Here is a great How to video available on our website, How To Replace a Pool Pump Capacitor.
 Reply


?     Asked on 8/14/2016 by Val

Hi, My 2 HP Hayward SPX1615Z1MNS Maxrate Motor will not start, I can hear humming noise. Could it be the run capacitor problem? Or run capacitor doesn't effect starting the motor?
 Reply

A  Answered on 8/20/2016 by InyoPools Product Specialist Lennox H.

Hi Val, The Run Capacitor does not affect the motor starting just it's running capability. This motor does not have a start switch either so the windings are bad so you will have to replace the entire motor.
 Reply


?     Asked on 5/28/2016 by Sherry

Hayward Super ll Pump 2HP Capacitator blew out. Gentec 97F9606 25uf +6 50/70Hz 370VAC RD-25-370 do you carry this or is there a correct substitute one. Leslie Pools sold me one & pump only works from 10 min to 1 hr & shuts off overheated ??? Do I need a whole new motor ??
 Reply

A  Answered on 6/4/2016 by InyoPools Product Specialist Lennox H.

Hi Sherry, This capacitor is the correct replacement base off the info you've provided. If the motor is more than 5 years old I would recommend that you replace the entire motor.
 Reply


?     Asked on 1/23/2016 by Tony

The capacitor I'm replacing from a STA-Rite (model XP-1241 120 VAC) pump motor is labeled as such: 20UF/ 330VAC 50HZ. What is a comparable sized capacitor you sell?
 Reply

A  Answered on 1/25/2016 by InyoPools Product Specialist Lennox H.

Hi Tony, The 20MFD 370 Volt Run Capacitor (RD-20-370) will be the correct replacement capacitor.
 Reply


?     Asked on 1/23/2012 by Guest

I need to replace my the capacitor on my 1.5HP pool pump. Do you carry the capacitor I need?
 Reply

A  Answered on 1/23/2012 by InyoPools Product Specialist Patrick P.

Please note that capacitors store an electric charge and should be handled with the utmost caution and care. We do not encourage handling a capacitor without any type of safety measures in place and highly recommend contacting a professional service company for repair/replacement. For those that feel comfortable changing the capacitor here's  >How to replace a pool pump capacitor. In order to match up the capacitor you will need more specifications on the capacitor. You will need to match the voltage, the MFD, whether or not the capacitor is a >run or >start type and the actual dimensions of the capacitor body.
 Reply


Top
Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Screwdriver, Pliers, Socket Set

Pump motor would not run

Written on 10/8/2017 by Guest

Cheched starting and run capacitor.
One was bad
Replaced the bad one but motor still did not run
Need to remove motor so I can inspect motor
