What are the port measurements (from the ground) for the Pentair Clean and Clear Plus cartridge filter?
Reply
The measurements for the Pentair Clean and Clear Plus cartridge filter are as follows: top port is 15.5" on center from the ground and the bottom port is 8" on center from the ground.
Reply
After 4 years, the top half of the housing on my filter has fine fiberglass hairs sticking out of the composite material. I presume this is from breakdown of the outer portion of the composite, due to exposure to the Sun. This makes the housing impossible to handle without getting the glass fibers stuck in your hands. Is there a recommended paint I can use on the exterior to protect it from further breakdown? Possibly Krylon Fusion, since it is made for use on plastics?
Reply
Eric O., I would recommend visiting your local paint store for recommendations on what type of paint to use if that's the direction you want to go, since we do not carry that type of paint.
Reply
I am looking to replace an old style Clean & Clear Plus Clamp Kit with Tension Control - but I want the old model not the new
Reply
Robert, Only the new style Clamp Assembly, PT5000/Clean & Clear (190003) is available.
Reply
We purchased this home with a pool in November 2015. Now I am getting the pool ready and it has a Purex/Pentair/Pac Fab CC420P filter system. I am experiencing "fiberglass itch" from the lid. If I rest my arm on it, then it gets all prickly, itch as if I've been working with fiberglass insulation. Is there any type of clear coat polyurethane or anything else to seal the exterior so as to avoid this itch?
Reply
Hi Jerry, We do not have anything specifically but you can check your local hardware store.
Reply
I have a crack in the bottom of my filter housing #160301. Can these be patched with fiberglass or other kit ?
Reply
Hi Joe, The answer to your question was answered in our Poolside Chat Episode #20.
Reply
Do you have a complete, specific parts list of what is included in the package purchase? I understand top and bottom tank and pressure guage and four cartridges are included. What about the ring gasket, the bottom manifold and pipe connection, exterior clamp, etc ...?
Reply
Hi Ron, here is the Parts List for The Pentair Clean & Clear Plus all of the items in this diagram are included with this filter.
Reply
I have a 24x12x 5max 4min depth pool what is the best clean clear plus filter system for my pool?
Reply
my clear plus 420 cracked just above the stainless strap that holds the upper and lower half together. Any ideas why?
Reply
Hi. It's hard to confirm why but tightening the strap too tight can cause the lid to crack.
Reply
My filter drain plug needs replaced, can I buy a new one?
Reply
Hi, Danny. Replacement parts including the Drain Plug are available and is listed on the Pentair Clean & Clear Plus Cartridge Parts Diagram page.
Reply
Hi and thank you for being there and helping us. I have a Seahorse fsh-400 cartridge filter that I’m very ready to put out or under the pasture. I’m most inclined to get the Pentair clean and clear plus 420 sq ft #160301 to replace the seahorse which is way more filter than I need but I’m happy with that and wanted to thoughts on which clean and clear plus you think I should get to replace the seahorse. Thank You
Reply
The Clean and Clear Plus Filter 420 Sq. Ft. - 160301 is an ideal replacement for the FSH400. The 400 refers to 400sqft. of effective filtration and the 160301 will offer 420sqft. of effective filtration, it can handle up to 150 gallons per minute provided by a pool pump. Please use the link http://images.inyopools.com/cloud/documents/pentair-clean-and-clear-plus.pdf to view the brochure.
Reply
what is the base of the Pentair filter 160301 ?
Reply
Hi, Harry. The Tank Bottom Assembly - 178578 (1998-Current) will fit based on when your system if it was within the specified date.
Reply
I am replacing it with my old unit Pentair model FNS 48 . please advise me. Also what is the height from the bottom to the out let ?
Reply
Hi, Harry. This is a good replacement option, from the base to the outlet is 8.05 inches.
Reply
I am just wondering whether something like this is crated in wood for shipping to prevent damage? What is the process if I receive it and it is damaged do I refuse it and send it back or contact you to resolve?
Best,
Tom
Reply
These are not crated when shipped. They are in the original box from the manufacturer. If the unit comes damaged then you would just need to take some picture and either refuse and call us or just call us so we can set up the carrier damage claim then set up a new order for you.
Reply
what size filter does this use
Reply
Hello - the Pentair 160301 filter uses the Clean & Clear Plus 105 Replacement Cartridge (PCC105) - PL0120.
Reply
I am replacing a very old steel DE filter, my pool is 33,000 gallons. It is a rectangular pool 16ft by 36 ft with the deepest area being 9ft. My pump is a Jandy self priming maxlift 10ft pro series. Will this filter work for my pool? Thank you
Hi, Jennifer. This filter will be adequate for your size pool and pump.
Reply
Hi I have an 18x42 inground pool what filter should I get the 320 420 or 520sq ft
Reply
Hi for your size pool we would suggest this Clean and Clear 420 Cartridge Filter
Reply
i have an approx. 22,000 to 25,000 gal rectangle pool. What size filter should i get 320 420 or 520?
Reply
Hi Craig, so there are a number of variables to consider when sizing a pool filter. Here is a guide that we put together called "How To Size a Pool Filter" that should help with that.
Reply
If the cartridge filter is too large for the system (using a variable speed pump), e.g. a turnover at 4 hours rather than 8 hours,
is there any problem?
Reply
Hello Young, having an extra capacity filter is not an issue. Here is a guide that we put together that better explains called "Can a Filter Be Too Oversized?"
Reply
I am interested in updating my filter to the Clean and Clear 420. Is there an install kit I can order at the same time? Are they in stock as of now or a wait period?
Thanks,
Rich K.
Reply
Hello, there is no install kit per se for this unit, it is in stock and has an approximate delivery lead time of 2-6 business days.
Reply
I currently have a Pentair DE filter with the inlet connect on the bottom and the outlet connect on top. It looks like this filter has the inlet on the top and the outlet on the bottom. Is this correct? There is not a ton of room around the current filter so I am just wondering whether I can replumb to match the change in the inlet and outlet pipe locations.
Thanks,
Tom
Reply
Hello Tom. On the Pentair Clean & Clear Plus model CCP420, the water inlet is located on the TOP, the outlet is located on the BOTTOM. If you are removing a Pentair DE filter with Multiport this may open sufficient space for the installation of the CCP420.
Reply
I switched from a de filter, to a clean and clear ccp420. but the multi valve is now sending the water into the centre of the filter which should be the outlet. what would be the correct 2" multivalve to use now?
Reply
Good day, Les, the Pentair Pool Products Clean & Clear Plus 420 Cartridge Filter would not be installed with a valve. It would be just piped directly into the system. If you wanted to install a bypass valve before the inlet so you would be able to drain the pool.
Reply
What is the estimated delivery time to slidell, La 70461?
Reply
Hi Donald, on average this filter would be delivered to your area in approximately 3-7 business days with tracking emailed to you once shipped as well. I have emailed you an estimate that you can convert to an order thats connected to your account with us if you choose to purchase.
Reply
Can this filter be used in a salt water pool?
Reply
Hello, yes this filter can be used with a saltwater swimming pool. I have also emailed you an estimate for this filter that you can convert to an order if you would like. Item is currently in stock and ready to ship.
Reply
