When should I change the sand in my filter?
Reply
You should change the sand in your filter every 5-7 years. You can generally tell that it is time if your pool water is not as clear as it normally is or when you notice the interval between backwashes is shorter. You can use > this guide to walk you through it.
Reply
We have had the same Jacuzzi filter for 15 years, and don't know how long previous owners had it. We need to replace it and I believe theL192C-7C will be correct for us, however I don't understand all these dimensions. our pool is 22,000 gallons. Do you think this is a good one for me to purchase? I cannot start our pool even though I have cleaned and filled it. We did buy a new Hayward pump last year, thinking that might be the problem. I think the filter is just to old. Please help
Reply
Hi Marilyn, for a 22,000 gallon pool I would suggest the next size larger filter which is the Jacuzzi Laser L225-7C. The larger filter will ensure that you do not put too much stress on your pump and will mean longer time between filter cleanings.
Reply
I have a 1 1/2 horse power pump. Will this work with the 160 top Mount Sand filter?
Reply
For a 1-1/2 HP pump we would suggest the 22-1/2" Jacuzzi Laser Sand Filter.
Reply
Is the L192-7C the same as the 190L, I need to replace a 190L thats leaking.
Thanks,
Bill Fischer
Reply
Yes, The Jacuzzi Laser L192-7c (94089192) it the newer model of your 190L.
Reply
My jacuzzi pump is dated 2004 for 24 ft round pool. The model number is 192L-7 Dial Valve for sand filter and DV7 -Pos for top mount dial...What model number matches this for jacuzzi
Reply
Hi Linda, The Jacuzzi Laser Sand Filter, Top Mount, L192-7C, 19", 1-1/2" Valve (94089192) will be the correct replacement for your 192L sand filter.
Reply
I'm looking for a filter that is around 50 gpm. Would the Jacuzzi, L192-7C, 19", 1-1/2" have the right gpm?
Reply
I purchased the 19" Jacuzzi filter. What horse power pump do I need?
Reply
Tammy- The size of the pump you need will depend on the size of your pool. But with the Jacuzzi Laser Sand Filter, Top Mount, L192-7C, 19", 1-1/2" Valve Part # 94089192 can accept up to a 1.5 HP pump.
Reply
What setting is waste when vacuumING
Reply
Hi Terry, If you are vacuuming heavy debris, you would set the valve on "DRAIN" to have the debris go out the waste port. If vacuuming light debris, you could set the valve on "FILTER" to save pool water.
Reply
My customer has this pump (L192C-7C) and is looking for 4 bags of 50lbs of Silica Sand (0.4mm-0.55mm) is this something you sell? Please advise if I can buy direct from you or if you have a Canadian distributor.
Thank you
Sylvia
BDI Canada Inc.
Reply
Hi Sylvia, Unfortunately we do not carry the silica sand as it is too expensive to ship. You should be able to pick this sand up at any hardware store.
Reply
I have a 18X33 above ground pool with a 1 HP pump motor. I need to replace the sand filter. It is Jacuzzi Laser L160. The dimensions are close to the L192-7C. Is this correct?
Reply
The different between the two are that the L160 is a 16" and the L192 is a 19" sand filter so it'll be able to take a higher flow rate if needed.
Reply
We have a L192-7C and we think that we need an o-ring because of leaking. Can you tell what size we would need?
Reply
Jacuzzi 39263009
DV ASSY 7-POS 1-1/2NPT with manufacture date of 2002
Would your model PART#94089192 work to replace our filer.
The sand filter part says its a model 190L
Thanks for your help!
Reply
Hi Stacy, This Jacuzzi L192-7C filter model will replace the 190L.
Reply
Hi, I have a 10,500 gallon in ground pool. The motor is 1hp. What would be the proper part number for a jacuzzi sand filter?
Thanks in advance
Seth
Reply
Hi Seth, This filter can be used with an 1 hp pump if the flow rate is around 46 gpm.
Reply
What are the power requirements (in volts and amps) of this filter? Would it work connected to a 2hp pump?
Thank you!
Reply
Hi Charlie, Filters does not require a power source and this unit can be used with a 2 hp pump if the flow rate does not exceed 47 gpm.
Reply
I have a Jacuzzi L192C & is pouring water out the bottom of the tank is there an o-ring there, if so where can I buy one?
Reply
Hi Ronna, There is not an o-ring on the bottom of the filter other than the o-ring for the drain plug.
Reply
Is there any warranty from manufactor or vendor?
Reply
Hello This filter has a 24 month warranty from the date of purchase. Here is a link to the Jacuzzi Warranty Card if you have additional questions.
Reply
will this handle my 35000 gallon swimming pool
Reply
This filter is too small for a 35,000 gallon pool. I would recommend the Jacuzzi Laser Sand Filter, Top Mount, L192-7C, 19", 1-1/2" Valve - 94089192. This will accommodate pools from 29,700 gallons to 39,600 gallons.
Reply
Bought the L192C this year and has done great! Preparing to shut it down for winter and did my last backwash. I had some sand come out through the discharge hose. This has not happened before. Is that normal or could there be an issue?
Reply
Hi, David. Inspect the unit to make sure everything is in place. it could be that the water pressure forced a little bit of sand up through the diffuser.
Reply
Hello, I have a Jacuzzi 190L-7 sand filter that has a leak on the seam of the tank.it looks like the model#L192-7C is a direct replacement for it.My question is my sand filter has 2 inch pipe connected to it,can I mount my existing dial valve to the new sand filter.Will the bolt holes line up for my dial valve on the new tank.Thanks...Eric
Reply
Good afternoon Eric, If you purchase the same filter yes.
Reply
Hi, Do you deliver to the UK please? Also, I need just the top mounted valve for the L192C-7 Jacuzzi sand filter. Do you sell this separately?
Thanks
Michelle
Reply
Hello Michelle- We do ship certain items to the UK. Keep in mind that the cost of shipping will include the cost of shipping this from the MFG to our office in Orlando, FL and then out to you. As for this entire filter we can not ship that to the UK, but the valve assembly we can. The valve for the L192c-7 would depend on whether or not you have a clamp on valve or bolt on. For the clamp on you would want the Dvk-7c Valve, Clamp Type - 39263020K, if your valve bolts on you would need the Valve, Dial, 7 Position - 39262803R.
Reply
Is the Jacuzzi L192C overkill for 12000 gl pool w/ 1 1/2 hp Purline pump,(2"valve) 12 feet head. Should I just stick to the L160?. Thanks!
Reply
With the flow rate you would actually need the next size bigger so that you do not damage your filter, part number 94089225.
Reply
I have a 190L filter tank. I placed a new drain plug to stop a drain plug leak. Still leaks. Can the drain threaded nozel on the tank be replaced?
Reply
Hello, I apologize, but you would have to replace the whole tank to replace the threaded nozel on the tank. The Filter Tank 190l (94080190) - 4626-40A is no longer available on our site.
Reply
My 10 year old Jacuzzi sand filter L192 began releasing sand into my pool last year. Can you tell me what the problem is?
Reply
Hello Bob, There is a broken lateral that would cause sand to come back into your pool.
Reply
I have a Laser 192 Jacuzzi Sand Filter. How do you get the laterals up, so I can remove sand. The laterals do not rotate.
What are my options for getting the sand out.
Reply
Hi, Terry. You first will have to remove the sand before you ca remove the laterals. You can manually scoop the sand out or use a shop vac.
Reply
Hi, I have a filter L192C. I put 200 lbs sand in it. Was it the right amount ? Also, I am sure I didn't break any laterals. Since I changed sand, i have sand in the pool. What's the reason do you think ? Thanks.
Reply
Hi Jean-Paul, 200 Lbs. is the correct amount of sand for the Jacuzzi L192-7C Laser Sand Filter. If you added the sand prior to adding some water to the filter tank then you may have broken laterals when adding the new sand. Typically broken laterals is the culprit for sand back in the pool but the only way to check is to remove the sand and inspect the laterals.
Reply
The label on the top of the filter that tells me the 7 operations has faded after one season. Can I get a replacement label? Is there a way to make sure this doesn't happen again?
Reply
Hi, Paige. The decal is not available as a separate part, you'll have to replace the DVK-7 Cover - 39262605R. You can try to keep the filter in a shaded location.
Reply
I have to replace the sand in my pump. The model number is L192C-7C from what i read here, I need 200lbs of sand. Do I put water into the pump before adding sand? After all the sand is in place, do I fill the pump with water?
Reply
Hi, Meghan. You can fill the tank halfway with water before adding the sand to the filter. It is not necessary to fill the tank up with water after the required amount of sand has been added. Instructions are available in our How To Change Sand In a Sand Filter and How To Install a Pool Sand Filter guides.
Reply
hi I have a Jacuzzi laser L192c the system has been working good for 10 years now replaced the sand with glass once
just started to have a problem....I think the multi valve spider seal is passing because when its stops I can here air sucking in and when it restarts it blows the air back into the pool do you think its the spider seal thanks.
Reply
Hi, David. The problem that you're experiencing is not caused by a bad diverter seal. It is caused by an air leak on the suction side of your system. Our How to Identify and Correct Air Leaks guide will assist you in resolving this issue.
Reply
192-7C Sometimes there is a small leak out the backwash pipe after switching to Filter
Are the spider orings in the Diverter that might be the cause? It is not leaking around the exterior of the Diverter
For 3 years there seems to be a dust on the bottom of the pool after the pump runs. I originally thought algae (mustard although it was a dark brown in colour),
then I thought it might be the spider orings causing this. I did change the sand 6 months ago but that did not stop the problem
Reply
Usually, water leaking out of the waste/backwash port is a sign that the spider gasket within the valve itself has gone bad. You would need to provide us with the valve model number so we can cross-reference that gasket for you. As far as debris on the floor, yes that could be dead algae that sand filters sometimes have difficulty filtering or merely dirt of some sort. Sometimes placing the valve into the waste position then vacuuming the sediment out is a good approach.
Reply
I have the Jacuzzi Laser L192C-7 as listed. During this opening season, I quickly found out my standpipe cracked and am in need of a new one. Does the L190 standpipe assembly fit the 192? I'm having a hard time trying to find the piece I need without spending the bank. All of my snap-on laterals are fine, it's just the standpipe. Can you point me in the right direction of an item number or part that I can purchase?
Reply
Hi, The Jacuzzi Laser L190 Stand Pipe does not work on the Jacuzzi L192C-7 filter. However, we do carry the Jacuzzi L192C-7 Stand Pipe here. We currently have 2 in stock ready to ship.
Reply
I have a laser 192 sand filter. I am obviously doing something wrong . I put the shark vacuum in to clean the bottom and when I turn the handle to the filter setting the water is being drained out of the pool through the backwash hose. What am I doing wrong? Also dirty water is being sent to the pool through the jet . Please help.
Reply
Usually, this is a sign that the spider gasket has gone bad. You can replace that but we would need to know the model of that multiport valve so we can locate that gasket for you. If you cannot locate that, you can always email us images of that valve to upload@inyopools.com so we can identify it for you.
Reply
I have a Jacuzzi Model 190 laser pool filter, it seems when the pump is running and my filter online in the filter position there is a little water that is being discharged to the drain line, so water is letting by while in the filter mode, maybe other positions as well. Not sure what is causing this..?? Thanks...Dave
Reply
This is a sign that the spider gasket has gone bad in the multiport valve on the top of the filter. It can be replaced. You would just need to know the model of the valve itself and we can advise on the specific gasket needed.
Reply
We have a model do assy 7-pos 1-1/2 v-fon jazzing laser sand filter. We would like to know the symbol for waste and also what the check mark symbol means. Ther is no writing on the filter that tells us what the symbols mean.
Reply
Hi. You can use the Laser Sand Filter User Guide to identify the symbols on the valve.
Reply
how much sand required for this filter
Reply
Good Afternoon- You will need 200lbs of sand for the Jacuzzi Laser Sand Filter, Top Mount, L192-7C, 19", 1-1/2" Valve
Reply
I have a Jacuzzi Laser 160 model...bought 23 years ago...replaced pump last year with a 1.5 hp pump, would this filter be the one I need? L192-7C, 19" 24" above ground
Reply
Hi, Linda. This filter will be sufficient for your pool.
Reply
Can I use "Filtra Balls" in this sand filter? If so how much and do I still need to use some sand to support the laterals? Thanks
Reply
Hi, Albert. You can use "Filtra Balls" with this sand filter. You will need 2 lbs of the Filtra Balls.
Reply
I have a jacuzzi 190 L is this the replacement and does it come complete with valve ass
Thanks Chris
Reply
Hi, Chris. Yes, this is the current replacement for the older Jacuzzi 160L model. It is complete with the valve and lateral assembly. It does not include the 200 lbs of sand required.
Reply
I have a 23,000 gallon pool and I need to replace the filtewr. I bought a nw 1.5 Hp pump last year I would like a Jacuzzi replacement filter for my inground pool. Do you have the L225c-7c if so how much is it.
Reply
We unfortunately no longer carry the Jacuzzi sand filter series. Please consider the Hayward sand filter series which are another great brand.
Reply
How does one replace the pressure gauge on this filter?
Reply
You would turn off the pump and unscrew the pressure gauge and then replace the pressure gauge with this Jacuzzi Laser Pressure Gauge
Reply
Can I use Silica #0 sand in a jacuzzi sand filter? Hardware store says that's what used for pool sand filters but it look too fine compare to what I took out.
Hi, Albert. Unfortunately, you can. You will have to use No. 20 silica sand.
Reply
I have a Jacuzzi Laser sand filter #L192C-6C. Recently, I've noticed pool water is leaking at the backwash valve while in filtration mode. What causes this?
Reply
Hi, Audrey. That is caused by a faulty Diverter Gasket located in the valve.
Reply
I have a L192C laser sand filter and need to purchase laterals or both laterals a manifold it seems it’s no longer being sold what other options do I have to get these?
Reply
Unfortunately, there is no listed replacement for this lateral and manifold assembly. You can always confirm directly with the current manufacturer Carvin/Cantar at 1 866 979-4501.
Reply
Hi, I moved into my house and the last owner left the sand filter, I think it's a Laser 192. The tag is no longer readable. Here's pictures of it.
I would like to know what sand I should put AND the quantity.
And the Spec sheet if it's available. Thank you
Sebastien, The Laser 192 filter takes 200 pounds of 20-grade filter sand. You will be able to find the sand at most local pool stores or hardware stores.
Reply
We have a Jacuzzi sand filter 192. We have to replace the standpipe. Which model we need? Would this model L190 (42376004R) fits? Thanks for the help.
Reply
Hi Gizèle, The model L190 (42376004R) will not fit the 192 filter. You will need this Jacuzzi 192L Standpipe which we currently do have in stock.
Reply
I have an older ( 15 Yr ? ) Jacuzzi sand filter and I need a new stand pipe assembly. How do I determine what model of Jacuzzi filter I have?
Please compare your filter to these Jacuzzi Laser Filter Dimensions to determine which model you have.
