Part # HP50HA

Warranty SEE OWNER'S MANUAL

Alternate Part #'s HAYHP50HA

Product Description

Hayward’s HP50HA, a new 45,000 BTU horizontal fan heat pump that can more efficiently heat in- or above-ground pools up to 13,000 gallons.

Hayward wanted to introduce an economical heat pump, right-sized for smaller in-ground and above-ground pools. The technological advances of Hayward’s new heat pump will help to provide pool owners with the ideal water temperature in an energy-efficient manner.

Features include:

  • 45,000 BTU heating capacity
  • Uses less energy than a natural gas or propane heater
  • Also includes a cooling mode to help lower water temperature
  • High-efficiency titanium heat exchanger
  • Extremely quiet operation
  • Hot temperature defrost system to start in lower temperatures
  • Electronic, programmable timer

Pools equipped with the HP50HA are designed to economically extend the swimming season. It will literally allow pool owners the opportunity to swim longer into the evening hours, earlier in the spring and later in the fall. Pool owners with smaller pools now have an efficient heating solution right-sized for their applications.

Applications

  • In- or above-ground pools up to 13,000 gallons
  • See HP50A & HP50HA Manual for installation requirements
Top

?     Asked on 10/14/2014by Guest

Can you connect your pool pump electrical and Pool Pilot salt water controller directly to the HP50HA system so that all systems run on the HP50HA timer. The pump is 1 1/2 HP.
 Reply

A  Answered on 10/14/2014 by InyoPools Product Specialist Patrick P.

No, the timer on the HP50HA does not control a pool pump and salt water chlorinator.
 Reply


?     Asked on 1/24/2015by Barrett Salta

How many gallons is the HP50HA and the HP50TA good for?
 Reply

A  Answered on 1/26/2015 by InyoPools Product Specialist Alex V.

Barrett, Both heat pumps are good for up to 13,000 gallons.
 Reply


?     Asked on 4/17/2015by Frank

What type of power source is needed for heat pump? 110/220?
 Reply

A  Answered on 4/18/2015 by InyoPools Product Specialist Patrick P.

Hi Frank, The power supply needed for the Hayward HP50HA is 208-230V.
 Reply


?     Asked on 4/20/2015by Inyo Visitor

What does is cost to run this unit? Does it have an efficiency rating?
 Reply

A  Answered on 4/20/2015 by InyoPools Product Specialist Brian M.

The cost to run the unit is dependant on the price you pay per kilowatt hour. It is similar to the price to run an air conditioner during the summer.  The efficiency rating can be found on this brochure
 Reply


?     Asked on 4/30/2015by Inyo Visitor

Would this unit be compatible with a solar electric powered home?
 Reply

A  Answered on 4/30/2015 by InyoPools Product Specialist Robert M.

Hello Dave - This unit will require a 20 amp breaker and 230 voltage. If your system can provide that, the heat pump will work.
 Reply
