Part # W560
Dimensions 13" L x 7.5" W x 7.5" D
For pools with heavy debris, Hayward leaf canisters are available. The large capacity canisters trap leaves and other large debris before they reach the pool's pump and filter system. The superior design allows the water to bypass the debris and maintain proper flow to the pump. The lexan see-thru construction allows you to immediately know when emptying is necessary.
This leaf canister plugs directly into the hose system of the Hayward Pool Vac Ultra and Hayward Navigator Pool Cleaners. It is simple to install and will save you time that was once spent cleaning your swimming pool. This is a must have if you own a Hayward Navigator or Hayward Pool Vac Ultra.
Click here for more Hayward Navigator
If I have 20 foot 1.25” hose connected to my filter what can I use to make the connection? I would buy a second hose to connect to the vac head, then place this between both hoses? Can you recommend any part numbers?
Would I need one or two axv092 pieces to connect this to a standard pair of 1.5 hoses?
Hi, Tallguynb. You will only need (1) one Hose Connector - AXV092.
will this work with the Jacuzzi J-D 300 pool cleaner
Hi, Fred. Yes, it will.
where in the suction lines do you install the hayward w560. I have 6 3' suction hoses in my poo
The Standard Leaf Canister - W560 would be installed before the last section of the hose.
Can this be used with the Zodiac MX8 Elite? Thanks. Ken
The W560 will not work with the Zodiac MX8. Part number W26705 would be the correct leaf canister for the MX8.
Can the 560 be used with the Lady Bug vacuum hoses and are there any other parts like clamps needed?
Hi Debbie, Yes this Leaf Canister can be used with the Lady Bug pool cleaner and there are no other parts like clamps that are needed.
Does the leaf basket work the Hayward Blu suction vacuum that you sell?
Yes, it will work with the Hayward Blu suction cleaner.
Do these canister have to attached to a robot vaccum system via the skimmer or side suction? Or can they be attached in line with a manual vaccum head attached to a pole? If yes, then what type if any fittings are needed to complete the conections between the two hose ends and the canister?
That leaf canister fit in between the standard vacuum hoses so you would be able to use it on a manual vac, suction-side, or pressure side cleaner, robotic cleaner use their own filter system.
I cannot separate the canister from the cap to remove the strainer. Does it unscrew or does it pull apart. I was able to remove the clamp that holds the cap in place, but can't budge the clear plastic dome. What is the trick to separating the dome from the cap?
After you unscrew the ring you will be able to pull the cap off. It might be on there tight because of the pressure so you will have to use a little muscle.
Will the Hayward Leaf Catcher Part # @560 work with a Pentair Sand Shark Hoses? Also, Do you have a leaf catcher that will set inside the skimmer and have connection to the Pentair Sand Shark Hose?/? Thnx, Mark O'Dell
Good afternoon Mark, This leaf canister will work with the sand shark hose. You can use a leader hose if you want to use it in the skimmer.
will this work with the pool cleaner, 2 wheel model?
Hi, The Hayward Standard Leaf Canister will work with The Pool Cleaner 2 Wheel by Poolvergnuegen.
I have a leaf catcher plumbed into my system just ahead of the pump that has a crack in it. Can the w560 be used to replace it?
Hi Jeff, These leaf canisters are not designed to be plumbed with pvc, you can use the Waterway Inline Filter or the Pentair Inline Filter.
I bought a Hayward leaf canister w560 .... all my pool hoses are 1 1/2 inch with the standard 1 1/2" hose cuffs. How do I make the connection from the leaf canister to the Hose .... the canisters odd connection with the two protrusions ( 1 5/8 " ? ) I tried several standard 1 1/2 hoses / adaptors nothing works. Can you advise ? Thanks Mitch
Hi Mitch, You can use the Hose Connector (AXV092) as an adapter to connect you hose to the Hayward Leaf Canister.
Will this canister work with barracuda or kreepy hose lines? Thanks.
Yes, the leaf canister will work with Barracuda and Kreepy Krauly hoses.
Does this leaf canister work well for long Scotch pine needles?
Hello, This canister is designed for collecting leaves and larger debris before it gets to the pump basket. The holes are open enough to allow the occasional pine needle through. We have no specific information available to determine the effectiveness of this canister in relation to pine needles, but from a personal opinion viewpoint, you are adding another line of defense which is better than nothing.
Can this be used with above ground pools and can it be used with diver Dave cleaner?
Yes, this leaf canister can be used with above ground pool cleaners, including Hayward's Diver Dave.
Can this be used with above ground pools and can it be used with diver Dave cleaner?
Hi Cheryl, This Leaf Canister can be used with an above ground pool and with the Diver Dave Cleaner.
I intend on purchasing the Pool Cleaner 4 Wheel Cleaner and this leaf catcher.Can pool skimmer socks be used in the leaf catcher to catch small debris? Would it be better to get a skimmer cap with spout for the cleaner hose to attach to and have the skimmer sock in the skimmer basket? Thanks.
Hi Jerry, The Skimmer Socks can be used with this Leaf Canister, either option will work just as good.
Will it work on The Pool Cleaner 2 wheel by poolvergnuegen
Hi, The Hayward Standard Leaf Canister will work with The Pool Cleaner 2 Wheel by Poolvergnuegen.
Will this work with The Pool Cleaner 4 Wheel Cleaner?
That leaf canister will work perfectly with the Pool Cleaner 4 Wheel Cleaner.
Can I use this w560 leaf cannister to keep leaves from getting into my lines or pump basket?
Yes this leaf cannister amongst a few other ones are designed to catch leaves and larger debris. This keeps debris from reaching plumbing lines, pump baskets and it even makes emptying it out easier being that it is right at pool level.
Where in the hose line should the leaf canister be attached?
According to Hayward, you would have one hose coming out of the skimmer and the W560 would connect to the end of this.
The Most Helpful Review
3 0
(5 out of 5 stars) Simple to use and effective
Reviewed By: Michael O. from Mesa, AZ ()
Pros: Easy to set up and use
Cons: None
Easy to set up, easy to use and to clean out. Stops palm tree debris and other things before they get to your pump. Well worth the money.
Was this review helpful to you?
The Most Recent Reviews
(4 out of 5 stars)
Reviewed By: ()
Works well with Hayward Blue swimming pool cleaner. Only complaint hard to get cover off to empty.
Was this review helpful to you?
(5 out of 5 stars)
Reviewed By: ()
Just as shown
Was this review helpful to you?
1 0
(4 out of 5 stars) good leaf canister
Reviewed By: Greg C. from san Diego, CA ()
Pros: steardy
Cons: difficult to open
The standard leaf canister is steardy and works well but a bit difficult to open
Was this review helpful to you?
0 1
(4 out of 5 stars) In-line Leaf canister
Reviewed By: Tom T. from Oakdale, CA ()
Pros: Reduces leafs going through pump system
Cons: none
Just put leaf canister on. It appears to be working as advertised.
Was this review helpful to you?
3 0
(4 out of 5 stars) Great addition to my Swimming Pool Cleaner
Reviewed By: Jerri B. from York PA ()
Pros: Easy to use and clean out.
Cons: Doesn't come with any instructions.
My pool is surrounded by woods so summer storms often pollute the pool with blown in needles and leaves. The design of my pool makes it inconvenient to stop and clean out the pump trap. With this device the leaves and debris are collected in-line. I can easily disconnect it and dump it.
Was this review helpful to you?
2 0
(5 out of 5 stars) Perfect Cleaner
Reviewed By: CHRISTIAN M. from LANCASTER, CA ()
Pros: Great invention
Cons: None
Its used as a primary filtration system by collecting large debris before it reaches your pool pump. There are less dirt going into the main filter. Its easy to maintain and clean. It keeps the vacuum pressure more stable.
Was this review helpful to you?
3 0
(5 out of 5 stars) a must have for pool cleaner
Reviewed By: Orlandoguy from Orlando, FL ()
Pros: catches all the leaves from bottom of pool
Cons: top is hard to remove
a great item to have when useing a pool vac/cleaner.. the top was hard to remove the first time but after the first time it was alot easier to remove.. you only have to remove maybe 2 or 3 times a month... does a great job.
