LED Pool Bulb White Light 120V 35W - PL5849


Part # PL5849

By PureLine

  4.67 Average



Part # PL5849

Warranty 2 Year Warranty

Product Description


The PureLine replacement White LED is the white light only version of our popular color changing LED bulb. The PureLine bulb uses an Edison screw in base, so they install easily into your existing fixture in just minutes. Plus, LED technology makes them the most energy efficient and longest lasting bulb on the market.


  • LED technology
  • 80% Operational Cost Savings
  • Standard screw in light base for quick & easy replacement
  • Synchronize multiple lights to operate in unison
  • 50,000 hours Lifespan
  • 2-year warranty
  • 441- LED's


  • Hayward Astrolite SP058 Series
  • Pentair Amerlite 784 Series
  • Note: Not compatible with Swimquip Light Fixtures or Hayward SP0540 series.

Product Specifications

White Light
Pool / Spa Type:
120 V
35 W

?     Asked on 5/25/2020 by Michelle Martin

How do you replace the bulb. Detailed instructions please. Thank You!

A  Answered on 5/25/2020 by InyoPools Product Specialist Patrick P.

Here is an article and video with detailed instructions on How to Replace a Pool Light Bulb

?     Asked on 5/15/2020 by PATRICIA RIVERA

will this bulb fit my housing unit? Also, what gasket will I need? I only need to purchase a bulb and gasket, right? Sorry- new at this ??


A  Answered on 5/15/2020 by InyoPools Product Specialist Patrick P.

Hi Trish, Thanks for the photos those are helpful. Yes, you can use this PL5849 PureLine LED Pool Bulb White Light 120V 35W and you will need this Pentair Pool Light Lens Gasket This will be the only two items you require when replacing your pool bulb. We do have this Video on How to Replace a Pool Light Bulb which you may find helpful when you tackle this project.

?     Asked on 4/24/2020 by homayoon hatefi

I have changed my pentair pool bulb to led 120v bulb lasts 1-2 yrs and burns out why led life is so short

A  Answered on 4/24/2020 by InyoPools Product Specialist Hector F.

There could be a few reasons why a pool light bulb may fail prematurely. In examples, power surges, a leaking light gasket, many hours of use however if the bulb has failed within the warranty time please contact the retailer that you purchased it with and they can run a warranty claim on it.

?     Asked on 4/20/2020 by Micah Neil

Will this bulb work with my fixture and is 35watts enough?


A  Answered on 11/6/2020 by InyoPools Product Specialist Hector F.

Hi Micah, yes this bulb is compatible with your Pentair Amerlite light however this bulb is no longer available. You can however use the J & J Colorsplash model LPL-P2-RGB-120

?     Asked on 3/19/2020 by Gregory Hatcher

I have a Pentair fixture. I need a light bulb and a new gasket. Woul like to go with an LED bulb if possible. Here is what is printed on the label: E4117 No.U-481848 Label #98700600 Please let me know what you have that will work. Thank you


A  Answered on 3/19/2020 by InyoPools Product Specialist Lennox H.

Hi, Gregory. In order to confirm if this bulb is compatible, we will need the fixture series number. The Amerlite Lens Gasket (79101600) - O-170 is compatible with your fixture.

  • Commented on 5/5/2020 by Product Owner

    The light reads: series 7855xxxx, 7845xxxx, 7895xxxx watts 500 volts 120 bulb type R-40 goes on to read "use withModel No. 7821xxxx,7822xxxx,7823xxxx 79206700 or CN-5 fixture housing wet niche type Will this bulb fit? Will need 2 gaskets and bulbs . Thanks for your help.


    • Commented on 11/6/2020 by InyoPools Product Specialist Megan C.

      The PureColors bulb is no longer available. The ColorSplash LXG LED Pool Lamp 120V - LPL-P2-RGB-120 and Guardian Silicone Lens Extra Heavy Duty Gasket for Pentair Amerlite - LPL-G-P can be used. The Color Splash bulb is equivalent to a 300Watt incandescent. It is not recommended for larger pool or pools with darker surfaces as it will not illuminate well.

?     Asked on 6/13/2018 by

is this bulb compatible with the Jandy RS controller? I previous purchased an LED replacement bulb from another supplier and the RS can’t control it...

A  Answered on 6/13/2018 by InyoPools Product Specialist Lennox H.

Hi. The Jandy RS Controller will only be able to turn the light circuit on/off.

?     Asked on 6/12/2018 by Jon

I have a hayward wet-niche inground pool light SP0583L 500W 129v is the LED pool light 120v 35W - PL5849 the correct replacement along with the SPX0580Z2 lens gasket? Also, what is your return policy? Thanks

A  Answered on 6/14/2018 by InyoPools Product Specialist Andy O.

Hello Jon- The LED Pool Bulb White Light 120V 35W - PL5849 and the Hayward Astrolite Lens Gasket (SPX0580Z2) are the correct parts. Our return policy is 30 days as long as the item is in new and unused condition.

?     Asked on 5/31/2018 by Allen Trammell

My electrician asked me why a regular sealed PAR 30 LED lamp would not work as the base is the same.

A  Answered on 6/2/2018 by InyoPools Product Specialist Lennox H.

Hi, Allen. The base will work, however, the fixture size will determine if the bulb will fit.

?     Asked on 4/1/2018 by Tim Corsmo

Is this light compatible with a Pentair Amerlite fixture?

A  Answered on 4/1/2018 by InyoPools Product Specialist Patrick P.

Hi Tom, Yes this LED bulb is compatible with the Pentair Amerlite Fixture.

?     Asked on 4/1/2018 by Tim Corsmo

Converted to ColorSplash bulbs and am unhappy. Too dim and white color is very blue. Thinking of converting again to white LED. Does this light produce a true white similar to an incandescent bulb? Is the 35W LED comparable to a 500W incandescent?

A  Answered on 4/2/2018 by InyoPools Product Specialist Lennox H.

Hi, Tim. This bulb does have a pure white illumination.  This bulb is equivalent to a 300-400 watt incandescent bulb.

?     Asked on 10/23/2017 by Don

will this LED bulb work on the SP-583-L fixture?

A  Answered on 10/24/2017 by InyoPools Product Specialist Lennox H.

Hi, Don. Yes, this bulb will fit the SP-583-L Fixture. I will also recommend that you replace the Astrolite Lens Gasket - SPX0580Z2.

?     Asked on 9/9/2017 by Steve

What are the dimensions of this bulb?

A  Answered on 9/11/2017 by InyoPools Product Specialist Lennox H.

Hi, Steve. Click the link to view > Product Dimensions

?     Asked on 9/7/2017 by

I see that the PL5849 is 2600 lumens. Is there anything brighter? The one I had is 6000k

A  Answered on 9/13/2017 by InyoPools Product Specialist Patrick P.

Hi Dale, 2,600 lumens is the brightest we have. I was not aware that there was an LED pool bulb as bright as 2,600 lumens, is it possible the 6,000K is the Kelvin rating? The Kelvin rating on this bulb is 6000k

?     Asked on 6/1/2017 by K

Will this bulb work in a HAYWARD SP0573LN50 replacement light?

A  Answered on 6/1/2017 by InyoPools Product Specialist Patrick P.

Unfortunately this bulb does not work on the Hayward SP0573LN50

?     Asked on 5/31/2017 by Kent G

How many lumens does this white only LED bulb put out? Trying to upgrade a pool to meet the SCDHEC standard of 8.33 lumens per square foot for a ~ 3100 square foot pool with 4 existing 500 R40 lights

A  Answered on 5/31/2017 by InyoPools Product Specialist Patrick P.

Hi Kent the Lumen rating for this bulb on white is 2,600 lumens.

?     Asked on 5/16/2017 by Christine

Looking to replace light blub . Old American Products 250 Watts/ 120 Volts/ Bulb Type T-3 (Aqua-Lumin) need a replacement. Something using less energy.

A  Answered on 5/17/2017 by InyoPools Product Specialist Lennox H.

Hi, Christine. Unfortunately, there is not a LED replacement option for the AquaLumin fixture. The Pentair AquaLumin III Lights are the only replacement option.

?     Asked on 5/15/2017 by

Is this led build dimable? It not, do you have dimable led bulbs?

A  Answered on 5/15/2017 by InyoPools Product Specialist Lennox H.

Hi. We do not have any dimmable LED bulbs.

?     Asked on 4/1/2017 by

I'm looking to replace my 500 watt pool bulb, is the LED Pool Bulb White Light 120V 35W - PL5849 comparable to 500 watts?

A  Answered on 4/2/2017 by InyoPools Product Specialist Patrick P.

The PL5849 is comparable to a 400-500 watt standard incandescent bulb.

?     Asked on 3/25/2017 by Patty

Will this work in all inground pool light fixtures?

A  Answered on 3/26/2017 by InyoPools Product Specialist Patrick P.

Hi Patty, This bulb works in the majority of inground pool light fixtures but not all. If you could email us the details on your light fixture we can confirm if this bulb will work.

?     Asked on 3/6/2017 by Tom

How many amps does this take?

A  Answered on 3/7/2017 by InyoPools Product Specialist Lennox H.

Hi, Tom. This uses 0.29 amps.
