A.O. Smith 3/4 HP Square Flange 56Y Full Rate EE Motor - B2661

$185.99

IN STOCK
FREE SHIPPING

Part # B661

By Century Motors

  5 Average

Details

Top

Part # B661

Warranty 1 Year

Manufacturer Code B2661

Alternate Part #'s 071313, 071313S, 10-165198-06, 1203165411, 16358, 165198, 165890, 177120, 177449, 193992, 35-5391, 5KCR38SN6147X, 7-165198-06, 7-177449-03, 7-193992-06, 716519806, 8-165198-03, 8-165198-06, 8-165198-40, 8-177449-03, B2661, BPA449, C1447, C1499, EB661, K48K2P101A1, K63CXESC-4790, QC1072, SQ207E

Product Description

A.O. Smith Centurion replacement motors for Pentair WhisperFlo, energy efficient, full rated pumps. Specifications: HP = 3/4, RPM = 3450, Voltage = 115/208-230, Amps = 11.2/6.0-5.6, Service Factor = 1.67, Frame = 56Y, Shaft = Threaded.

Note: NOT California Title 20 Compliant.

California Title 20 Compliant Options:

Motor Dimensions Motor Dimensions
Motor Image Motor Image

Product Specifications

Motor Name:
0.75 HP B661 & B2661 Replacement Pool Motor
HP:
0.75 HP
Speed:
Single
RPM:
3450 RPM
Volts:
115/208 - 230 V
Amps:
11.2/6.0 - 5.6 amp
Service Factor:
1.67
Total HP:
1.25 HP
Frame:
56Y
Stock #:
B661 or B2661
Shaft:
Threaded
Overload Protector:
Auto
Dimension Letter:
C
Dimensions:
13.1 in.
Commonly Used On:
Pentair
Flange:
Square
Energy Efficient:
Energy Efficient
Notes:
NOT California Title 20 Compliant
Top

?     Asked on 10/25/2019 by Don Davis

I need to replace my Sta-rite motor #196249. I am looking at your PureLine PL2853, AO Smith B2853, and AO Smith B2661. Will they all work as replacements, and how can I estimate the energy savings by going to the higher efficiency motor to see if it justifies the higher price? Also what seal kit would I need?

 Reply

A  Answered on 10/25/2019 by InyoPools Product Specialist Lennox H.

Hi, Don. You can use either option and use our How Much Does My Pool Pump Cost to Run? guide to calculate operation cost. You will also need the SuperMax Tune Up Kit - GOKIT78.
 Reply


?     Asked on 9/7/2019 by Peter

Is this a DP motor as this will be installed outside.
 Reply

A  Answered on 9/10/2019 by Industry Professional

Yes it is, & it is usually installed outdoors.
 Reply


?     Asked on 8/10/2019 by BW

Are the mounting holes in this motor, spaced at 5" center to center ?
 Reply

A  Answered on 8/15/2019 by Industry Professional

yes straight across they are 5"
 Reply


?     Asked on 6/12/2019 by Chris

Can you recommend the options I have to replace this motor with a square flange

 Reply

A  Answered on 6/13/2019 by InyoPools Product Specialist Matt S.

Hello - this motor is a 56J round flange motor; a square flange is not able to mount to the same pump housing. Your replacement motor would be the 3/4 HP Round Flange 56J Full Rate EE Motor - B127.
 Reply


?     Asked on 3/14/2019 by Craig

I have a Pentair WhisperFlo which is leaking between the motor and the pump. My pool service says that the motor bearings are also sounding bad and a new motor is needed. Taking them at their word, I'm having trouble identifying a replacement motor. My current unit is a model WFE-3, 0.75 HP / SF 1.25 / 115V. Your website shows this motor is not California Title 20 compliant and I live in the Golden State. Replacement motors appear to have a higher HP rating. What direction can you offer?

 Reply

A  Answered on 3/14/2019 by InyoPools Product Specialist Lennox H.

Hi, Craig. The A.O. Smith 3/4 HP Square Flange 56Y Dual Speed Full Rate Motor - B2981 is the replacement motor that will work for your application. You will also need to get the Toggle Switch - 2512558-001 and the Whisperflo Tune Up Kit - GOKIT32 or GOKIT32SALT
 Reply


?     Asked on 1/28/2019 by

I have a 177449. This b661, b2661 is a replacement but not in california. What other motor can I replace it with that will ship to California
 Reply

A  Answered on 1/28/2019 by InyoPools Product Specialist Lennox H.

Hi. Your replacement options will be the SQS1072R (Dual Speed) or the ECM16SQU (Variable Speed).
 Reply


?     Asked on 10/27/2018 by Paul

Hello, I am helping a friend with his large outdoor fountain. It had a Century Centurion 7-177449-03 pump connected to it that has gone bad. Can you tell me if this is a direct bolt in replacement? I.E. output shaft / mount / etc...
 Reply

A  Answered on 10/31/2018 by InyoPools Product Specialist Hector F.

The direct replacement motor is the B661
 Reply


?     Asked on 6/16/2018 by

Does this B661 motor come in tan to match my whisperflow pump?
 Reply

A  Answered on 6/16/2018 by InyoPools Product Specialist Lennox H.

Hi. The OEM Whisperflo Motor - 355008S to this B661 can be special ordered.
 Reply


?     Asked on 10/28/2017 by

I believe the bearings have gone in just a short time for this pump. Is it possible to replace the bearings so we can quiet in the pool and the neighbors not angry at me?
 Reply

A  Answered on 10/30/2017 by InyoPools Product Specialist Lennox H.

Hi. The replacement bearing for this B2661 motor is Part # 10000353. You will need two bearings, one for the shaft end and one for the opposite shaft end.
 Reply


?     Asked on 9/19/2017 by dan

Hi, was wondering if this pump will work with whisper Flo WFE-24 and replaces my AO Smith 177449 model?.
 Reply

A  Answered on 9/19/2017 by InyoPools Product Specialist Lennox H.

Hi, Dan. This B661 motor can be used to replace Part #177449. The Whisperflo Tune Up Kit - GOKIT32 or GOKIT32SALT is a recommended item when replacing the motor.
 Reply


?     Asked on 9/8/2017 by schafer

My motor is going bad for for pool. Pentair WF-23 / 011771. is this the correct replacement motor? if So, is there anything else that I will need when replacing?
 Reply

A  Answered on 9/11/2017 by InyoPools Product Specialist Lennox H.

Hi, Schafer. The B852 is the correct replacement motor for the Pentair  WF-23 / 011771. You will also need the Whisperflo Tune Up Kit - GOKIT32 or GOKIT32SALT
 Reply


?     Asked on 6/23/2017 by G-Factor

Hello, I have a WhisperFlo WFE-3 with a AO Smith 177079 motor. I need to replace the motor and wanted to confirm this is the proper part. If there is anything else you recommend doing while I have the pump apart, please let me know along with the pieces and parts I will need to purchase from you. Thank you in advance for your help, it is appreciated. Cheers! G
 Reply

A  Answered on 6/24/2017 by InyoPools Product Specialist Hector F.

You can use this model motor and we advise to replace the seals as well. The standard one is the GOKIT32 and if you have a salt water pool then it would be the GOKIT32SALT
 Reply


?     Asked on 6/20/2017 by Rockie Chan

I have AO Smith 7-186020-02, 2.5HP, SF1.04, TYPE-CX, FR-Y56Y, PH1,RPM-3450, Volts-230, APM- SF 11.5, need to buy a replacement motor for it. and which tune up kits .Thanks
 Reply

A  Answered on 6/20/2017 by InyoPools Product Specialist Patrick P.

Hi Rockie, Based on the motor information you supplied you will require the B2840 2.5 HP Replacement Motor. To determine the seals you require we would need for you to send us a photo of your pump to include where the plumbing goes in and out of the pump. To send the photos simply reply to this email with the photo or you may email to upload@inyopools.com and state you are looking for a seal replacement.
 Reply


?     Asked on 5/29/2017 by

I have to replace the drain plug on my century centurian (187400). Do you have this part?
 Reply

A  Answered on 5/29/2017 by InyoPools Product Specialist Hector F.

This motor is typically used on the Letro booster pump so as long as that is your model then your drain plug part number is 3280-15 and the o-ring is part number 3285-60.
 Reply


?     Asked on 5/22/2017 by

hi trying to replace a.o. smith cat b121, part 7-164298-24 fr s56c 3/4 hp pool pump motor.
 Reply

A  Answered on 5/22/2017 by InyoPools Product Specialist Patrick P.

Hi, you will require this B121 3/4 HP Keyed Shaft Replacement Motor
 Reply


?     Asked on 4/30/2017 by

I have to replace my pump (193992). The equipment there now is a Jandy 340 cartridge filter & Jandy .75 HP Stealth pump. I'm trying to estimate the costs for replacement. Do I need to replace both the Jandy (Century Centurion 28907CH) & the Stealth pump? Thanks
 Reply

A  Answered on 4/30/2017 by InyoPools Product Specialist Lennox H.

Hi. You do not have to replace the pump if it's in good condition or if the pump is less than five years old. I would recommend replacing the motor and the pump seals.
 Reply


?     Asked on 4/6/2017 by Randy

I have bad bearing in pump motor. thought might be better replacing motor. Have Pentair part number 0-177449-03 fr R56Y 3/4 HP what is the replacement motor for this/
 Reply

A  Answered on 4/6/2017 by InyoPools Product Specialist Scott W.

Unfortunately, I was not able to pull up the part number you provided. Do you happen to have a CAT# or model# on your motor? Also, I will need your pump model as well so we can get you the correct shaft seal to go along with your motor.
 Reply


?     Asked on 3/28/2017 by

I need to replace my motor for my pool. Part# is 7-177449-03 volts 208-230/115 amp 40 rpm 3450. What motor do i need
 Reply

A  Answered on 3/28/2017 by InyoPools Product Specialist Andy O.

Hello- The correct replacement motor for your 7-177449-03 is the 3/4 HP Motor EE - Full Rate (B661, B2661).
 Reply


?     Asked on 2/25/2017 by Guest

I need to downsize my whisperflo motor # 011775 (2.5hp) to a 3/4 HP motor. Would you please recommend the type of impeller that I need to purchase with this motor?
 Reply

A  Answered on 2/27/2017 by InyoPools Product Specialist Hector F.

The impeller would be part number 5074-27A.
 Reply


?     Asked on 2/20/2017 by brian f

have a Stay-Rite Max-E-Glass II pool pump. Model no. is P4E60-186L. It is a 3/4hp motor, FR 48 and SF 1.65. I have 2 questions. First, which A.O. Smith motor would replace this pump? The second question is is there a more efficient motor available that I could use that would fit the existing parts so I would not have to get all new parts.
 Reply

A  Answered on 2/20/2017 by InyoPools Product Specialist Scott W.

The B661 is an energy efficient motor, but if you want something more efficient you would want to go with either a dual speed or variable speed motor.
 Reply


?     Asked on 12/28/2016 by Bill

Will this motor work as a replacement for a Franklin #778 model 1103025420?
 Reply

A  Answered on 12/29/2016 by InyoPools Product Specialist Adam Y.

Good morning Bill, I am showing Motor Vert. Pool Sweep 3/4hp (b663) as the correct replacement. This item is not in stock and considered special order allow 3-4 weeks for delivery.
 Reply


?     Asked on 12/12/2016 by San

Can I use this motor to replace my Hayward SP2605X7?
 Reply

A  Answered on 12/13/2016 by InyoPools Product Specialist Lennox H.

Hi, San. No, you can not. You can use either the UST1072 standard motor or the UCT1072 energy efficient motor. I would also recommend getting the Hayward Super Pump Tune Up Kit GOKIT2 or GOKIT2SALT.
 Reply


?     Asked on 11/18/2016 by Dean

I have an AO Smith motor # 177449 on my water feature. The previous owner used a timer to start/stop and I would like to start it with an RF remote mounted in the 220 volt feed line near the pump. Do you have this remote?
 Reply

A  Answered on 11/18/2016 by InyoPools Product Specialist Adam Y.

Good morning Dean, Do you have the part# for this remote?
 Reply


?     Asked on 10/7/2016 by

Will this model fit the Pentair WFE-3 011512?
 Reply

A  Answered on 10/10/2016 by InyoPools Product Specialist Lennox H.

Hi. Yes, this B661 motor will fit the Pentair WFE-3 011512 pump.
 Reply


?     Asked on 9/27/2016 by HARRY

I am looking for a replacement motor for a Pentair pump model WF-23 part #011771
 Reply

A  Answered on 9/28/2016 by InyoPools Product Specialist Stacey M.

Hello Harry, the 3/4 HP Motor EE - Full Rate (B661, B2661) would work for your  WF-23 part #011771. Please make sure to replace GOKIT32 if you are replacing motor.
 Reply


?     Asked on 9/26/2016 by

Will this motor replace a magnetek 7-187400-20....B668
 Reply

A  Answered on 9/27/2016 by InyoPools Product Specialist Stacey M.

Hello, No if you look at the specs on the 3/4 HP Motor EE - Full Rate (B661, B2661) the frame, amps, dimensions don't match up.
 Reply


?     Asked on 9/12/2016 by Renee

Ok I have a Magnetek E-Plus, part number 7-165198-06, will this motor fit my pump?
 Reply

A  Answered on 9/12/2016 by InyoPools Product Specialist Scott W.

Yes, that would be the correct replacement motor according to the part number you provided.
 Reply


?     Asked on 8/1/2016 by charlie

does the b661 motor come with impeller
 Reply

A  Answered on 8/1/2016 by InyoPools Product Specialist Alan M.

No, the motors do not come with an impeller or a shaft/pump seal. You would need to know the make and model of your pump to determine the correct parts associated with that pump.
 Reply


?     Asked on 6/23/2016 by Joe

I'm looking for a motor for the WhisperFlow WFE-24C It currently has an Emerson C55CXKLS-5006, 1hp sf1.25, which overheats and has to cool for 10 minutes before restarting. Try sooner and the thermal protection switch trips
 Reply

A  Answered on 6/26/2016 by InyoPools Product Specialist Alex V.

Joe, Please provide an image of the motor label. There are some specs we will need to match.
 Reply


?     Asked on 6/11/2016 by

im looking for a 3/4 hp motor for the WhisperFlow WFE3
 Reply

A  Answered on 6/12/2016 by InyoPools Product Specialist Matt S.

The correct motor replacement for the WhisperFlo WFE-3 is the B661 3/4 HP Energy Efficient.
 Reply


?     Asked on 5/23/2016 by David

I have AO Smith 7-177474-01, will the 2661 fit?
 Reply

A  Answered on 5/23/2016 by InyoPools Product Specialist Matt S.

Yes, the B661 is a compatible replacement for the B847 motor currently on your pump.
 Reply


?     Asked on 4/8/2016 by V

What is the GPM flow rate?
 Reply

A  Answered on 4/8/2016 by InyoPools Product Specialist Hector F.

Gallons per minute ratings are based on a number of factors. Total feet of head, and model of the front pump housing that these motors are bolted to are needed to give an approximate rating.
 Reply


?     Asked on 4/6/2016 by JASON

I have a Pentair 1/2 hp #177449 230 volt witch is starting to make noise. What motor would you recommend? The motor is 3 years old.
 Reply

A  Answered on 4/7/2016 by InyoPools Product Specialist Robert M.

Hello Jason - The replacement motor is model B661.
 Reply


?     Asked on 3/17/2016 by Sam

Should I use this to get energy savings by replacing the motor in my SuperFlo 340038 (1 HP x 1.25 SF), or should I get the 1HP EE instead? Is a variable speed even better? What are approx differences in electric consumption between the three? (25,000 gallon in-ground, pump 2' above water line, and pushes an additional 8' up to solar water heating)
 Reply

A  Answered on 3/18/2016 by InyoPools Product Specialist Lennox H.

Hi Sam, You can use this motor verses the B854 to achieve "good" energy savings, a Dual Speed motor B2981T will offer you "better" energy savings and a variable speed motor ECM16SQU will offer you the "best" energy savings. Between all these option you can cut operation cost by 33-80 percent.
 Reply


?     Asked on 2/6/2016 by Patrick

I have just replace the motor from my pool pump with the B661 from Inyo Pools but when I turned back the electricity the rotor does not turn and all it does is a loud hum. I have removed the motor from the pump and verified that the rotor rotates freely. Does this motor only come with one capacitor inside the top hump? I checked the capacitor with a digital multimeter and it appears to store charge okay. Can you please advise on my next step? Thanks Patrick
 Reply

A  Answered on 2/8/2016 by InyoPools Product Specialist Lennox H.

Hi Patrick, Confirm the voltage that the motor is wired for, either 115 or 230 volts. If the motor is wired and set to the correct voltage setting and you're still having problems, let us know and we can get a replacement sent out under warranty.
 Reply


?     Asked on 7/7/2015 by Mandee

I am replacing the bearing in my 177449 motor. Can you tell the part #'s??
 Reply

A  Answered on 7/8/2015 by InyoPools Product Specialist Dennis R.

Hi Mandee - Your motor uses bearing 203, front and back. The part number for the B661 bearings is 5270-31.
 Reply


?     Asked on 6/15/2015 by

I am replacing the bearings on a century pool and spa motor 1081 3/4 hp B625 and have lost the spring on the on the end that takes the play out of the shaft. How do I order another spring.
 Reply

A  Answered on 6/18/2015 by InyoPools Product Specialist Lennox H.

Century does not have that spring available as a replacement part, you can contact them directly at 937-667-2431 to see if they can send you a replacement. If not you may have to purchase a complete new motor.
 Reply


?     Asked on 5/30/2015 by Ioan

Hi, Can I use this pool motor to replace pool motor #186236?
 Reply

A  Answered on 5/31/2015 by InyoPools Product Specialist Patrick P.

You would actually require the B846 Replacement Motor here.
 Reply


?     Asked on 5/5/2015 by

My new motor gets extremely hot very fast when my pump is in filter mode. What could be causing this?
 Reply

A  Answered on 5/5/2015 by InyoPools Product Specialist Lennox H.

Here's a link to troubleshoot or diagnose what can cause your motor to get extremely hot.
 Reply


?     Asked on 2/26/2015 by DAVID

based on this motor what tune up kit should I get ? thank you.
 Reply

A  Answered on 2/26/2015 by InyoPools Product Specialist Wes B.

for your motor it would be the (gokit32) if you type it in on the website it will pull up.
 Reply


?     Asked on 2/26/2015 by DAVID

my motor is making too much noise , do I need to change the pump too or just the motor .
 Reply

A  Answered on 2/26/2015 by InyoPools Product Specialist Wes B.

As long as there is no leaks or cracks in the pump housing you should be just fine changing the motor and shaft seal part number (gokit32). Also just double-check the impeller and diffuser and any o-rings you may come across, They should all be round, If any are flat they will need changed.
 Reply


?     Asked on 2/25/2015 by DAVID

I found a model a (Motor 3/4) very close to what I need. So far the only difference is under frame. Mine shows a R56Y and your model shows 56Y. Is that a major factor?
 Reply

A  Answered on 2/26/2015 by InyoPools Product Specialist Robert M.

Hello David - This is not an issue. The R56Y and 56Y are the same frame.
 Reply


?     Asked on 2/16/2012 by Guest

I just finished replacing the shaft seal on my booster pump. As soon as I turned the pump on water was leaking from the shaft seal. Is it defective or am I doing something wrong?
 Reply

A  Answered on 2/16/2012 by InyoPools Product Specialist Patrick P.

Depending on the model, the installation of a booster pump shaft seal can be slightly different than a pool pump shaft seal. Some booster pump and pool pump shaft seals require that a silicone sealant be used on the outer areas of the metal seat of the shaft seal. The seal will need to be lightly hammered into the body of the pump. You can use a 1 inch PVC coupling or a piece of 1 1/4 inch PVC pipe and a rubber mallet. This procedure will apply to any pool pump or booster pump using a >PS-1000 style shaft seal.
 Reply


?     Asked on 1/19/2012 by Guest

I'm trying to replace the motor on my pool pump but all these numbers and abbreviations on the motor label are really confusing me. What do they mean?
 Reply

A  Answered on 1/19/2012 by InyoPools Product Specialist Patrick P.

Replacing a pool pump motor is not as difficult as it seems. You can try looking here. If you need help figuring out what the information on your label means. If you are still having difficulty figuring it out you can call us at our toll free number or you can send us a photo of your motor label here.
 Reply


?     Asked on 1/12/2012 by Guest

Why should I purchase a Tune Up Kit?
 Reply

A  Answered on 1/12/2012 by InyoPools Product Specialist Patrick P.

A Tune Up Kit includes all of the essential replacement seals and gaskets for the pump. The seals and gaskets should be replaced when installing a new motor on your pump. New seals will prevent the pump from leaking water or losing the prime. A Tune Up Kit will protect your motor and ensure that the pump is working efficiently.
 Reply


?     Asked on 1/12/2012 by Guest

Why do I need to purchase a new shaft seal?
 Reply

A  Answered on 1/12/2012 by InyoPools Product Specialist Patrick P.

We strongly recommend replacing the shaft seal. The purpose of a shaft seal is to prevent water from running down the shaft of the motor and into the motor housing. Water will damage the bearings and cause the motor to fail. A new shaft seal should be installed whenever a motor is replaced. The motor manufacturer can deny the warranty if the motor fails to due to water damage from a faulty shaft seal. To find your shaft seal you will need to visit our Pool Pump Parts Page or the Spa Pump Parts Page and select your make and model.
 Reply


?     Asked on 1/11/2012 by Guest

What is Service Factor?
 Reply

A  Answered on 1/11/2012 by InyoPools Product Specialist Patrick P.

Service Factor(SF) is a multiplier that when multiplied by the horsepower of the motor indicates the total permissible horsepower loading that may be carried when the motor is operating at rated voltage and frequency. The most important thing to remember when replacing a motor is that the replacement motor's horsepower times its service factor must be equal to or greater than the original motor's horsepower times its service factor. The Service Factor rating can be found on the motor label. See Step 4 of our How to Read a Pool Motor Label guide.
 Reply


Top
Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Screwdriver, Socket Set, Adjustable Wrench

Motor failed

Written on 7/17/2018 by Guest

Turned off all power. Then removed all wiring - took picture of the wiring for later use. Removed all nuts and bolts and separated motor from pump. Cleaned all parts. Reassembled parts to new motor and connected wiring. Restored power, and the new motor worked perfectly.

Were these instructions helpful?


Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Screwdriver, Nut Drivers, Pliers, Socket Set, Wrench Set

1     0

The bearings on my American Products Ultra Flow Pump Siezed

Written on 1/9/2018 by Guest

Always Lock Out / Tag Out power source when working on electrical equipment!!!

My Motor had been sqealing for some time and the bearing finally gave up the ghost.
I contacted INYOPools for a direct motor replacement via Email
INYOPools team provided me a direct link to the part
Ordered part and within a couple of days pump motor arrived
In the link were instructional videos with how to remove the motor and install various motors / pumps. While similar, there were a couple of differences. I supplemented my knowledge with several external videos while waiting for the pump to arrive.
While I easily removed the motor, I had a challenge removing the rear seal. Nothing I did could separate it from the motor.
I went to a local pool supply and was luck enough to find a replacement rear seal and picked up Tune Up Kit including Shaft Seals (I neglected to buy these at the same time and these are *critical*)
Once I had all the parts on hand, I watched the video one more time.
In less than 20 minutes hands on work, I had the new motor installed and working in the existing pump.

Lessons Learned - Buy the Tune Up kit if buying just the replacement motor; Watch the videos suggested by INYOPools; watch other videos too.

Always Lock Out / Tag Out power source when working on electrical equipment!!!

Were these instructions helpful?


Top

Review Summary

 (Average 5  out of 5 stars)
12 Rating
5 star:

(12)
4 star:

(0)
3 star:

(0)
2 star:

(0)
1 star:

(0)

The Most Helpful Review


The Most Recent Reviews
