Volute Replacement Kit (357149)

$199.99

IN STOCK
FREE SHIPPING

Part # 5074-10B

By Pentair Pool Products

  4.8 Average

Details

Top

Part # 5074-10B

Manufacturer Code 357149

Dimensions 6.65" X 1.4"

Alternate Part #'s 073742, 357149, 600535, 75417, 788379659691, PAC-101-1465

Product Description

WFE Volute Replacement Kit With New Lid Assembly (replaces 074565)

Top

?     Asked on 10/23/2018 by

I have WFDS-3, Serial #1-12-F03, Does this Volute kit replace the entire pump with the exception of the electric motor? If not, what would I need to purchase in order to replace the entire (Non electric motor) of this pump.?
 Reply

A  Answered on 10/23/2018 by InyoPools Product Specialist Lennox H.

Hi, This is only the Volute or housing. You will need to also get the Impeller - 073127, Diffuser - 072927, Diffuser O-ring - 071444, and the hardware if needed.
 Reply


?     Asked on 8/3/2018 by roger oschman

What size are the in/out connections
 Reply

A  Answered on 8/3/2018 by InyoPools Product Specialist Hector F.

These ports have 2-inch inlet and outlet diameters.
 Reply


?     Asked on 7/16/2018 by mike

Does the replacement kit come with the diffuser (5074-13A) and the gasket seal (5074-09B)? Would you please list all the parts in the Volute Replacement Kit. Thank you.
 Reply

A  Answered on 7/16/2018 by InyoPools Product Specialist Hector F.

This volute kit includes the pump housinglidbasketshaft seal and seal plate.
 Reply


?     Asked on 1/8/2018 by Richard

Will it work as a replacement for Pentair whisperflo 1 hp model wf-26?
 Reply

A  Answered on 1/8/2018 by InyoPools Product Specialist Kevin G.

Hello, this would work with your model.
 Reply


?     Asked on 9/17/2017 by steve

will this fit my Whisperflo WF 23 3/4 hp the housing where the motor bolts onto has deteriorated on the bottom
 Reply

A  Answered on 9/18/2017 by InyoPools Product Specialist Lennox H.

Hi, Steve. This Volute Replacement Kit - 357149 will fit the WF-23 pump.
 Reply


?     Asked on 7/13/2017 by Peter

what type of fitting goes on the suction side of the pump? What type of threads?
 Reply

A  Answered on 8/29/2017 by InyoPools Product Specialist Andy O.

Hello Peter- The specific unions for that whisperflo are the Union, 11201-0154 (WhisperFlo Pump - SOLD INDIVIDUALLY).
 Reply


?     Asked on 5/19/2017 by Dave

Will this fit p/n #011524? Whisperflo pump w/switch wfds-28 230v
 Reply

A  Answered on 5/20/2017 by InyoPools Product Specialist Hector F.

Yes, this volute replacement kit will work on your pump model.
 Reply


?     Asked on 5/13/2017 by Richard

I have a crack in my volute, the pool is 30 years old, it's a purex triton whisperflo model WF-28, will part number 5074-10B work as a replacement? Thanks
 Reply

A  Answered on 5/14/2017 by InyoPools Product Specialist Hector F.

Yes this volute kit will work for your pump.
 Reply


?     Asked on 4/30/2017 by John

I just lost the motor off my Pentair Whisper Flo pump....what I'm looking at is either replacing the motor (bolting it on the old pump) or replacing the motor and pump entirely. I have around 15 years on the pump and motor (before the motor went out) and my question is does the pump piece (the Volute and all it's parts) wear out over time and need replacing periodically even if it's not broken?
 Reply

A  Answered on 5/1/2017 by InyoPools Product Specialist Patrick P.

John, Typically the pump housing does not go bad over time. The main items that need to be replaced over time are the motor, shaft seal and o-rings/gaskets.
 Reply


?     Asked on 3/28/2017 by Jim

Will this kit fit a 3hp Whisperflo pentair
 Reply

A  Answered on 3/28/2017 by InyoPools Product Specialist Stacey M.

Hello Jim, Yes this 5074-10B WFE Volute Replacement Kit With New Lid Assembly (replaces 074565) will fit the 3HP.
 Reply


?     Asked on 2/25/2017 by Don

Will it work for a whisperflow 2.5 hp Model # 011775
 Reply

A  Answered on 2/27/2017 by InyoPools Product Specialist Andy O.

Hello Don- The Volute Replacement Kit (357149) part # 5074-10B is the correct replacement for your Whisperflo Pump 2 1/2 HP - WF-30 011775.
 Reply


?     Asked on 2/18/2017 by JB

I have a Pentair Superflow 1hp pump. Cold weather cracked both the seal lid as well as the seal lid base causing a loss of vacuum. Motor is fine. Can you recommend the replacement part, volute, basket seal lid?
 Reply

A  Answered on 2/20/2017 by InyoPools Product Specialist Hector F.

Please view the parts diagram for your Pentair Superflo here. It looks to be keys number 4,5 and 7 would consist of the parts that you would need. Also you may want to consider replacing the seals as well being the gokit78.
 Reply


?     Asked on 6/4/2016 by Don

I have cracks in the volute. I may as well rebuild the whole pum. What else do I need in addition to this Volute Replacement Kit?
 Reply

A  Answered on 6/11/2016 by InyoPools Product Specialist Lennox H.

Hi Don, You will need the Impeller, Diffuser and Diffuser Hardware base off of the motor you have.
 Reply


?     Asked on 5/16/2016 by John

will this volute work with pentair whisper flow #011514? What other parts do you recommend replacing when making repair? Please specify part #s. thanks.
 Reply

A  Answered on 5/16/2016 by InyoPools Product Specialist Hector F.

Yes this volute kit will work with the Pentair Whisperflo.
 Reply


?     Asked on 5/13/2016 by Mike Brock

Does this kit include the impeller and diffuser?
 Reply

A  Answered on 5/15/2016 by InyoPools Product Specialist Matt S.

No, this kit does not the impeller or diffuser, it does include the pump housing, lid, basket, shaft seal and seal plate.
 Reply


?     Asked on 5/13/2016 by Mike

Will this fit my whisperflo 1 hp #011772?
 Reply

A  Answered on 5/13/2016 by InyoPools Product Specialist Hector F.

Yes this Volute kit will work for your model pump.
 Reply


?     Asked on 8/2/2015 by

will it work for a whisperflow 2 hp
 Reply

A  Answered on 8/3/2015 by InyoPools Product Specialist Joe S.

Hello, Yes this will work for the Whisperflo pump.
 Reply


?     Asked on 7/27/2015 by Duncan

Would this work with a whisper flow 1 1/2 horsepower pump
 Reply

A  Answered on 7/28/2015 by InyoPools Product Specialist Joe S.

Hello Duncan, Yes the Volute Replacement Kit (357149) will work for your whisperflo
 Reply
