  5. BV015

$19.99

Qty:
 ADD TO CART

Details

Top

Part # BV015

Alternate Part #'s 0250-15, 025015, 150-ES00, 25800-151-000, 6954, 26-395-1315, AMGHMIP150SE, CMP25800151000, SPG-56-6001, VLPBV015S

Product Description

Features:

  • PVC Type 1 material
  • Pipe socket designed with solvent cement trap
  • Deep socket -1¼" depth both ends
  • Buna-N O-Ring seal
  • HDPE seats
  • Tee handle - quarter turn on/off with stops
  • Acme thread on assembly nut
  • Working Pressure - 150 PSI @ 72º F; 100 PSI @ 120º F
  • 1½" & 2" IPS
  • Inexpensive, yet high quality; Meets ASTM specifications.
  • EPDM seats and O-rings for chloramine resistance.
  • Only ball valve with a 2-year guarantee.
  • Available in 1½" - 2" Union models.
  • Available in ¾" - 4" Non-union models.
  • Union models disassemble for service.

Product Specifications

Slip Size:
1 1/2 in.
Top
Ask A Question

?     Asked on 5/4/2013by Guest

Do you sell just the red handle on this ball valve?
 Reply

A  Answered on 5/4/2013 by InyoPools Product Specialist Patrick P.

Unfortunately we do not sell just the handle on this Flo Control ball valve.
 Reply


?     Asked on 6/30/2016by Vicki Leo

I can't figure out which way to place valve to vacume pool. I have a 20'x40 inground, and am unable to close one valve to use the vacume, we have 2 on/off valves, but the red handle has brocken, and I can't figure it out.
 Reply

A  Answered on 7/4/2016 by InyoPools Product Specialist Lennox H.

Hi Vicki, You will have to first repair the broken valve then isolate each port to find out which valve regulates the port. After that you will need to adjust the ports to provide enough suction to operate the cleaner.
 Reply


?     Asked on 5/28/2018by Inyo Visitor

What position , vertical. Or horizontal is the ball valve in when backwashing?
 Reply

A  Answered on 5/28/2018 by InyoPools Product Specialist Lennox H.

Hi. The Valve Handle in horizontal to the water flow is open and vertical will be closed.
 Reply


?     Asked on 5/15/2019by Ashley Neidhardt

Will this fit in the waste port on Hayward sandfilter multiporr to connect my waste hose too
 Reply

A  Answered on 7/24/2019 by InyoPools Product Specialist Hector F.

These will not actually fit onto or into the waste port but can be glued to 1.5 inch PVC that is connected to the waste port.
 Reply


?     Asked on 7/20/2020by Thomas Danielczik

If I cut out a piece of my 1.5" waste pipe to install this valve will it fit tight around the pipe sections with just glue to hold in place, or do I need additional adapters/unions?
 Reply

A  Answered on 11/16/2020 by InyoPools Product Specialist Hector F.

Hi Thomas, if you have standard 1.5 inch PVC pipe then this ball valve should glue right to that pipe.
 Reply


Top

Review Summary

 (Average 4.75  out of 5 stars)
4 Rating
(50%) 2 of 4 customer would recommend this product to a friend.
5 star:

(3)
4 star:

(1)
3 star:

(0)
2 star:

(0)
1 star:

(0)
Write A Review

The Most Helpful Review

1     2

 (5 out of 5 stars)  Easy Valve

Reviewed By:  84pool from Hawthorne, NJ ()

Installed to replace other, works a lot better, and completey shuts down water flow.


Was this review helpful to you?


The Most Recent Reviews

 (5 out of 5 stars)  Good and sturdy

Reviewed By:  Inyo Customer ()

Good and sturdy, heavy duty Schedule 40 PVC ball valve. Works well.


Was this review helpful to you?


0     1

 (4 out of 5 stars)

Reviewed By:  Inyo Customer ()

Appears to be solid with large valve handle


Was this review helpful to you?


0     1

 (5 out of 5 stars)  Pool Chiller Valves

Reviewed By:  Keystone ()

Works as described with pool chiller.


Was this review helpful to you?
