By Hayward Pool Products



Model # W32025ADC

Warranty 2 Year Limited Manufacturer

Alternate Part #'s HAYW32025ADC

Product Description



The all new Hayward Pool Vac XL introduces Exclusive AquaPilot technology makes Pool Vac XL faster and more efficient than any random style pool cleaner. Pool Vac XL moves in a predetermined series of right and left turns to systematically provide more thorough coverage of your pool's surfaces. It scoops up all types of debris and deposits it directly into your existing filtration system. No need for additional equipment or expense. For the ultimate in easy, trouble-free operation, leave your pool cleaning to the most sophisticated suction pool cleaner available, Hayward's Pool Vac XL.

Pool Vac XL gives you easy, trouble-free operation. And because it's powered by your existing filtration system, you don't have the expense of an energy-consuming booster pump. You won't waste time emptying or replacing debris bags. Getting that sparkling clean pool is easy and effortless with the Pool Vac XL. When you install your new Pool Vac XL as part of the Totally Hayward® System, you get the assurance of knowing you have a complete system, designed to work together for the best automatic operation and the cleanest pool possible.

Add a leaf canister to your Hayward pool cleaner so debris does not collect in your pump basket. The leaf canister fits between 2 sections of the pool cleaners hose, debris is now collected in the leaf canister rather than your pump basket.

Q: What is the difference between the Hayward Pool Vac and the Hayward Navigator?

A: The only difference between the Pool Vac and the Navigator is the shape of the head of the cleaner. The head of the Navigator is square or flat and the Pool Vac is more rounded. Both cleaners use the exact same internal compnents and the same hose, so if you ever need to replace parts in the future the parts for both cleaners would be the same. Some people say the rounded design on the Pool Vac performs a little better in the corners of the pool.


  • In-ground residential pools (Gunite / Tile)


  • Exclusive AquaPilot® – Pre-programmed steering pattern assures thorough pool coverage
  • Powered by your existing filtration system – No additional equipment required
  • Easy to use – Connects in less than 10 minutes to skimmer or suction port
  • Turbine Technology – Operates silently

Product Specifications

Cleaner Type:
Pool Surface:
Pool Type:
In Ground
Pool Size:
Up to 40' Long

?     Asked on 1/16/2012by Guest

Does this model come with the hose and what is the length of the hose?

A  Answered on 1/16/2012 by InyoPools Product Specialist Patrick P.

This unit comes with a complete hose assembly that is 40 ft. in length.

?     Asked on 4/3/2012by Guest

How many feet of hose are included with this cleaner?

A  Answered on 4/3/2012 by InyoPools Product Specialist Patrick P.

40' of hose is included with the cleaner.

?     Asked on 5/22/2013by Guest

How does the Pool Vac XL work? Are there any additional parts needed for installation?

A  Answered on 5/22/2013 by InyoPools Product Specialist Patrick P.

No, no additional parts or tools are needed. The Pool Vac XL operates off of the existing filtration system and installs in ten minutes.

?     Asked on 9/12/2014by Guest

My Pool Vac XL can't make it out of the deep end of my pool. Any idea why?

A  Answered on 9/12/2014 by InyoPools Product Specialist Patrick P.

Please make sure when installing the cleaner to have adequate lengths of hose. The hose should reach from the skimmer or vac lock to the furthest point in the pool, plus TWO extra hose sections.

?     Asked on 9/12/2014by Guest

I have a Hayward Pool Vac XL and the cleaner does not climb the walls? Why?

A  Answered on 9/12/2014 by InyoPools Product Specialist Patrick P.

There are a few reasons why this may be happening. FIrst of all the shoes on the cleaner may not be correct for the surface type. Please call 908-355-7995 for the correct shoes for your application. Another reason may be worn shoes or wings. The hose may be too short. There is also a adjustment for the rear flap. Please double check all of these possibilities.


Review Summary

 (Average 3.8  out of 5 stars)
5 Rating
5 star:
4 star:
3 star:
2 star:
1 star:

The Most Helpful Review

The Most Recent Reviews
