By Raypak



Model # 014781

Warranty 1 Year

Alternate Part #'s PR106AAPC, RAY014781

Product Description

RayPak Above Ground Pool/Spa Heater - 106A

The Raypak 106A is the perfect choice for above-ground pools and spas. Raypak is the only manufacturer of this size heater to use all the engineering and components utilized in our bigger gas heaters. The unit is fully serviceable and built for years of operation. This may be our smallest pool and spa heater, but its built to the same exacting standards as the rest of our products. Extend your swim season, open your pool earlier and close it later. Your pool is always ready when you have a Raypak on duty.

Basic Data

Model Number Full BTU Input Indoor Stack dia.
P-R106A 105,000 6”


PolyTuf Textured Powder Coating

The Raypak gas heater has a polyester-coated, non-corrosive cabinet that is more durable than solvent-borne and waterborne-coated metal cabinets. Every piece of sheet metal goes through a 7-stage wash system, making certain the powder paint has a perfect bond. Underneath the tough, yet beautiful finish you will find galvanized metal that offers superior rust prevention and years of durable service

Wind-Resistant Design

No need for fans to combat drafting problems under normal conditions. This heater is designed to draft naturally in outdoor installations with its exclusive low-profile design. It is so thoughtfully and carefully designed it actually protects itself from the things that tend to stifle ordinary pool and spa heaters. It delivers uninterrupted heating performance regardless of falling leaves, wind, airborne debris, rain, downdrafts, updrafts, sleet, snow, etc.

Polymer Headers

Prevent rust stains from harming your pool or spa’s surface, giving you years of trouble-free swimming pleasure.

All-Copper-Fin-Tube Heat Exchanger

The fin tubes of the heat exchanger are each made from a single piece of extruded copper. This integral-fin design allows maximum heat transfer to be attained and maintained. Raypak also uses thick stainless steel tube sheets for robust construction and rust free operation.


The 106 is available standard with an easy to use analog dial. The electronic ignition system requires external power (120VAC or 240VAC) and generates a pilot only when there is a call for heat. Units come with a 3 foot, 3 prong power cord.

2” Water Connections

Supplied with every Raypak 106 heater is a set of 2" flange connections to make your installation secure and effortless.

Automatic Bypass

The Raypak 106 comes standard with a built in water bypass so it can handle different GPM’s without having to adjust your flow rates manually. The bypass also helps keep a constant engineered flow through the tubes to help reduce condensation caused by cold water.

Burner Tray

Every burner tray is built to last, from the stainless steel burner deck to the aluminized metals used in the heat sensitive areas. Innovative design allows for the easy removal of the tray for servicing.

Fire Tile

A ceramic fiber combustion box keeps your heater running efficiently while keeping the outside jacket cool. By using this space-age material the heater won't retain residual heat after it is turned off, allowing it to be installed without the use of costly metal heat sinks.


Energy-smart Raypak heaters consistently achieve the highest efficiency ratings. They meet or exceed all federal and state standards.

Available for natural gas or propane.

Please note the Raypak model 106 is not designed to meet the emissions regulations in areas requiring Low NOx levels.

Reduce input 4% for each 1000 feet above sea level when installed above 2000 feet elevation.

California Customers Please Note:  South Coast Air Quality Management District ( SCAQMD) Area of Jurisdiction REQUIRES a Low Nox Heater be installed.  The following 6 California Counties are affected:  Los Angeles, San Bernardino, Ventura, Orange, Riverside, & Kern. Installing a non-compliant heater in these counties will void the manufacturer's  warranty and could result in a fine from your local code enforcement.
Click here for RayPak Low Nox Heaters

Product Specifications

105,000 BTU
0 - 1999 ft.
Heat Exchanger:
Heater Type:

?     Asked on 5/19/2015by john

I have a 15x26 semi in ground pool with a depth of 54". there are no gas lines in my neighborhood. I use oil to heat my home. Would i be able to get a propane heater for my pool and how many BTU's would i need to get? How does the propane get delivered and how often?

A  Answered on 5/21/2015 by InyoPools Product Specialist Patrick P.

Hi John, For a 15' x 26' pool I would suggest a 206,000 BTU Raypak Heater. For propane you would have a propane tank which normally sits on the side of the house or is burried in the ground. The propane company usually figures out your average useage and puts you on automated schedule, for example they would come out every 6-8 weeks to fill up the tank.

?     Asked on 10/8/2015by Andy

what is the efficiency rating of this heater?

A  Answered on 10/8/2015 by InyoPools Product Specialist Joe S.

the use of costly metal heat sinks.Fuel-EfficientEnergy-smart Raypak heaters consistently achieve the highest efficiency ratings. They meet or exceed all federal and state standards.Available for natural gas or propane.Please note the Raypak model 106 is not designed to meet the emissions regulations in areas requiring Low NOx levels.Reduce input 4% for each 1000 feet above sea level when installed above 2000 feet elevation.

?     Asked on 5/10/2016by Ruth

We have a 12 x 24 above ground pool, what pool heater would be suitable for us

A  Answered on 5/13/2016 by InyoPools Product Specialist Lennox H.

Hi Ruth, This 105,000 or the 156,000 BTU will be suitable for size pool. The 156A will heat your pool faster than the 105A unit.

?     Asked on 11/30/2018by Jon

Need an outdoor SPA heater app 350 gal Propane Elv 4400 ft

A  Answered on 12/3/2018 by InyoPools Product Specialist Joe S.

Good day if you are looking at a 106A Propane Millivolt you would need RayPak 106A Analog Control - 105K BTUs - Propane, MV (4000-6999 FT) - 014783.

?     Asked on 3/22/2019by Will

Would I have to run a special plug for this heater or can I plug it into a the already out door plug that we have?

A  Answered on 3/22/2019 by InyoPools Product Specialist Lennox H.

Hi, Will. This unit does not require any electricity. This is a millivolt system which uses a standing pilot to power the unit.
