By Hayward Pool Products



Model # CL220BR

Alternate Part #'s 42-150-1010, HAY-45-903, HAYCL220BR

Product Description

Automatic Chemical Feeders Efficient and maintenance-free, these durable, corrosion-proof auomatic chlorinators and brominators are ideal for new or existing pools or spas and work automatically with your pump and filter system.


  • Uses large or small slow dissolve tablets or sticks
  • Dial control valve lets you control and adjust the rate of feed
  • Easy-Lok™ threaded cover for safe and convenient access to add tablets or sticks
  • Unique finger-release catch provides extra security
  • Simple installation for do-it-yourselfers.
  • 1 year warranty


  • Chemical Capacity: 9 lbs
  • Dimensions: (W) 8-1/4 in. x (H) 15-1/2 in.
  • Weight: 46 lbs.

Flow Ratings: (GPM = Gallons Per Minute)
CL100 - Used with pumps with flow rating of 30-50 GPM
CL200 - Used with pumps with flow rating of 50-80 GPM
CL2002S - Used with pumps with flow rating of 50-90 GPM
CL110 - Used with pumps with flow rating of 30-50 GPM
CL220 - Used with pumps with flow rating of 50-90 GPM

Miscellaneous Notes

Note:Chemical feeders should always be installed after a pool heater.

CAUTION: Extreme care must be excerised when adding chemicals to your pool. Concentrated chemicals may react violently if they mix in the chemical feeder, causing a fire or explosion, which may result in PROPERTY DAMAGE, PERSONAL INJURY or DEATH.

CAUTION: Never use any petroleum based lubricants on cover O-Ring. Regular lubrication is necessary to allow for easy cover removal. Use non-petroleum based lubricants such as Jack's No. 327 lube or Ivory bar soap.

Click here for more Hayward Chlorinator

Product Specifications

Offline Spa Bromine
Small Tablet Capacity:
9 Lbs.

?     Asked on 8/26/2021by Janet Solomon

I have a Hayward brominator model C500BR and need a new O ring for the cover. Can you tell me the part number and if you have it in stock?

A  Answered on 8/27/2021 by InyoPools Product Specialist Craig C.

Hello Janet.  The Viton o-ring, part number 2111-03, is the correct replacement part for your Hayward Bromine Feeder model C500BR.  The o-ring is in stock and available.    O-ring,cover - Viton (438 Viton) O-12V

?     Asked on 5/17/2020by martha

do you supply Hayward brominator o rings

A  Answered on 12/4/2020 by InyoPools Product Specialist Hector F.

Hi Martha, the lid o ring for this Hayward brominator is part number 2110-06

?     Asked on 9/22/2019by Ian

I have a 2000 gallon spa. What size brominator should i have and where can i get it?

A  Answered on 9/23/2019 by InyoPools Product Specialist Michelle B.

Hello, We would recommend part number CL220BR for your size spa.

?     Asked on 3/23/2018by Sherry Kent

Why would I use an off-line brominator when installing a new in ground pool? Why not in-line which seems to make more sense to me rather than drilling holes to accommodate it.

A  Answered on 3/23/2018 by InyoPools Product Specialist Joe S.

Attached is the How To Decide Whether You Need An In-line or Off-line Chlorinator. I would recommend an Inline unit for a new build.

?     Asked on 8/24/2016by Inyo Visitor

how do you add bromine tablets

A  Answered on 8/24/2016 by InyoPools Product Specialist Stacey M.

Hello, To add your bromine, turn off system (pump, filter) and unscrew top cap (there will be overflow/spill of water coming out through the chlorinator). Just add your tablets into the water, add lube for your oring that is in the lid and screw back your lid. Turn pump/filter back on to flow bromine into system.

?     Asked on 8/17/2016by jodi barletto

I bought the CL220BE 2 years ago and the lid is so hard to turn. It is a nightmare when it comes to turning the cap off. I have to tap it with a hammer to get it to turn. What causes it to be so hard. Any tips would be greatly appreciated. Need to make a new system that you unlatch instead of turning. Thank You

A  Answered on 8/20/2016 by InyoPools Product Specialist Lennox H.

Hi Jodi, You can try to keep the lid o-ring lubricated. It sounds the cover o-ring is absorbing water causing it to expand making the cover hard to be removed.

?     Asked on 7/20/2016by Mike

I received a Series CL220EF chemical feeder that is labelled as a chlorine feeder. Can this be still used for bromine as this is the chemical I am using?

A  Answered on 7/20/2016 by InyoPools Product Specialist Alan M.

Yes you can use this chlorinator for both chlorine and bromine.

?     Asked on 12/17/2015by bryan

What is the difference between a brominator and chlorinator?

A  Answered on 12/17/2015 by InyoPools Product Specialist Charlie R.

A chlorinator dispenses chlorine, while a brominator dispenses bromine. Bromine is typically used as a substitute for chlorine in hot tubs and spas because it remains stable at higher temperatures. On the other hand, once temperatures pass 98 degrees, chlorine excess turns to gas, which produces an odor.

?     Asked on 6/30/2015by Inyo Visitor

What is the difference between an online and an offline brominator?

A  Answered on 7/1/2015 by InyoPools Product Specialist Hector F.

Online brominators are plumbed into the system after the filter and or heating unit while the offline is connected to the lines via holes drilled and hoses attached to them with fitttings and clamps.

?     Asked on 5/2/2015by M. Cass

What is the product number of a brominator for a 15 by 30 foot swimming pool?

A  Answered on 5/3/2015 by InyoPools Product Specialist Patrick P.

This would be the Brominator I would recommend for a 15' x 30' swimming pool.

?     Asked on 1/19/2015by tom

What is a brominator?

A  Answered on 1/20/2015 by InyoPools Product Specialist Robert M.

Hello Tom - A brominator is a chemical feeder that holds bromine tablets and feeds a desired amount of bromine into the water.

?     Asked on 1/30/2012by Guest

What is the difference between an inline and offline chlorinator?

A  Answered on 1/30/2012 by InyoPools Product Specialist Patrick P.

An inline chlorinator would be plumbed directly inline with the plumbing.  For an existing pool, this would mean a section of pipe would need to be cut out to install the chlorinator.  An offline chlorinator attaches to existing plumbing by chlorinator tubing (holes would be drilled into existing pipe to attach the tubing.)

?     Asked on 3/10/2007by Guest

Is there a feedback mechanism that tells the unit the chlorine balance in the pool? Is this a way for me to automate addition of clorine to keep it always at the correct level? Or, just another place to put the tab aside from the the drain basket?

A  Answered on 3/10/2007 by InyoPools Product Specialist Patrick P.

There is a dial on this unit which has a setting from 1-10 If you set the dial on 1 it will be letting the least amount of chlorine to the pool and if you have it set at 10 this would send the most amount of chlorine to the pool. So you can automate the feed of chlorine to the pool but you will still need to manually test your water. We do not recommend placing tablets in the skimmer basket because this high concentration of chlorine goes directly back to your pump and can cause corrosion to your pool equipment. If you do not go with the automatic chlorinator we would recommend at least going with one of our floating chlorinators so you do not damage your equipment you may view our floating chlorinators here http://www.inyopools.com/chlorinators_floating.aspx

?     Asked on 7/13/2006by Guest

Can I use granular, or must I use 3" tablets or stick?

A  Answered on 7/13/2006 by InyoPools Product Specialist Patrick P.

We recommend using tablets or sticks, and not to use granular with chlorinators.
