By Hayward Pool Products



Model # SP1084

Alternate Part #'s 50-150-1006, HPPSP1084

Product Description

Hayward 1084 Series Pool Skimmer for Vinyl/Fiberglass In-Ground Pools

The Hayward Auto-Skim Series is molded of rugged, non-corrosive ABS and has no joint below water level. The Auto-Skim feature a cover collar allowing 1 1/2" vertical adjustment and a snap-in-weir that automatically adjusts to 4 1/2" variation in water level. An optional float/by-pass valve is available. The auto-Skim can be used in either Residential or Commercial applications. Add an optional float valve and equalizer with a NSF approved cover to any Auto-Skim with a square cover to accommodate commercial requirements.


  • Pipe Size: 2" Female
  • Cover: Square
  • Throat Length: 8-1/2"
  • Color: White

Product Specifications

Pool Type:
Vinyl / Fiberglass
Port Size:
2 in.
Port Type:
Female Threaded
Opening Width:
7 5/8"
Opening Height:
5 5/8"

?     Asked on 11/2/2020by Bryan Haynes

Is there a throat extension available for the Hayward SP1084 skimmer?

A  Answered on 11/9/2020 by InyoPools Product Specialist Hector F.

Hi Bryan, so there is no throat extension for the Hayward skimmer model SP1084 but there is a collar extension part number 4040-24 if by chance that was what you were referring to.

?     Asked on 4/13/2020by Rachel Leslie

What is the best skimmer to use on my intex pool? Im looking to install a thru the wall skimmer my pool is 24' around

A  Answered on 11/19/2020 by InyoPools Product Specialist Megan C.

The Intex pools typically do not offer through wall skimmers for the design of their pools. You may contact them directly at https://intexcorp.com/ for further assistance to their skimmers.

?     Asked on 5/26/2019by Inyo Visitor

My skimmer faceplate measures 10 3/4 x 8 1/2 but it is listed as Hayward SP 1082-1-R,SP 1084-1-R will this fit my pool opening if I replace with this model?

A  Answered on 5/28/2019 by Industry Professional

yes it will

?     Asked on 4/14/2018by Patrick

How long is the throat of the vinyl Hayward skimmer? Is the cover changeable from the square lid to a round lid? Does this skimmer have just one hole on the bottom?

A  Answered on 4/18/2018 by InyoPools Product Specialist Lennox H.

Hi, Patrick. The throat is 8-1/2", the covers can be changed from round to square or vice versa only by purchasing and installing the Adjusting Collar. The skimmer has two suction ports.

?     Asked on 3/5/2018by Rachel

Skimmer cracked and leaking water below intake level. How to I remove and replace the skimmer

A  Answered on 3/6/2018 by InyoPools Product Specialist Lennox H.

Hi, Rachel. Removing and replacing an inground pool skimmer requires digging up your deck.

?     Asked on 4/12/2017by Dave

There is a 3/8"(approx) hole between the two 2" threaded openings, what is this for? thanks

A  Answered on 4/12/2017 by InyoPools Product Specialist Scott W.

One is the main drain for the skimmer and the other is for if you want to connect a suction side cleaner into the skimmer.

?     Asked on 6/17/2016by ben volz

does the sp1084 skimmer have a drain hole on the backside to release water out of the pool?

A  Answered on 6/18/2016 by InyoPools Product Specialist Alex V.

Ben, The skimmer does not have a drain on the back.

?     Asked on 4/20/2016by Willie

Is sp1084 skimmer the same size as sp1075-a

A  Answered on 4/21/2016 by InyoPools Product Specialist Lennox H.

Hi Willie, This skimmer can be used as a replacement for a vinyl or fiberglass surface pool, however, it will not be an exact drop in replacement.

?     Asked on 4/29/2015by Charles

Does the 1084 come with gaskets and face plate

A  Answered on 4/29/2015 by InyoPools Product Specialist Lennox H.

Charles, Yes the gasket and face plates is included with the complete skimmer.

?     Asked on 7/30/2007by Guest

The optional float by pass valve, what is it and how much does it cost?

A  Answered on 7/30/2007 by InyoPools Product Specialist Patrick P.

The optional float / by-pass valve provides a main-drain thru skimmer system plus an automatic safety by-pass for low water conditions. You may purchase the float valve assembly through this link http://www.inyopools.com/Products/07501352017468.htm
