Part # NE6450

Manufacturer Code PD1100-6

Alternate Part #'s PD11006

Product Description

Waterway’s Hi-Flo Above Ground Pump delivers superior and efficient performance at an affordable price. The Hi-Flo pump offers a higher flow rate than most above ground pumps for better circulation and filtration. You can easily rotate the wet end from vertical to horizontal, making it ideal for new installations or as a replacement pump.

Features

  • 1 1/2″ Union threads / 1 1/2″ FPT Intake and 2″ Union threads / 1 1/2″ FPT discharge
  • Powerful side discharge performance
  • Wet end can be rotated for easy installation
  • Large 6″ pump trap with 2-piece lid
  • High head capability
  • Trap is 2″ union x 1 1/2″ union / 1 1/2″ FPT





Product Specifications

HP:
1 HP
Speed:
Single
Volts:
115 V
Port Size:
1.5 in.
Cord Type:
Standard 3-Prong
Cord Length:
3 ft.
Top

?     Asked on 12/2/2021by Keith Miller

What is the max flow rate of this 1 hp water way pump
 Reply

A  Answered on 12/2/2021 by InyoPools Product Specialist Eric J.

Good afternoon Keith, the max flow rate varies from pool to pool and pump depending on the specs of your system. You can use the flow chart on the product page with your TDH (total dynamic feet of head) to try and calculate what the flow rate would be in your pool. I have a link to help you with sizing. How to size a pool pump.
 Reply


?     Asked on 5/20/2020by Chris

What goes into the hole behind filter housing on pump I’m confused as not working with my current set up Thanks

 Reply

A  Answered on 12/30/2020 by InyoPools Product Specialist Hector F.

Hi Chris, that hole is the discharge port where the plumbing would be connected there and then will need to be connected to the pool filter.
 Reply


?     Asked on 6/9/2017by Sal

does the waterway 1 hp hi flo come with horizontal hook up to filter
 Reply

A  Answered on 8/3/2017 by InyoPools Product Specialist Alex V.

Sal, The pump comes as pictured (vertical). If you need a horizontal discharge, you can rotate the housing
 Reply


?     Asked on 5/25/2017by Tony

I am looking for a replacement pump 18x33 above ground pool motor is 1hp 115 volt would like a 1.5 hp and it needs to have an on /off switch , as our electric is inside garage , not an outlet with in 6 ft of pool
 Reply

A  Answered on 5/25/2017 by InyoPools Product Specialist Scott W.

A 1.5HP pump is nice if your filter is able to handle the increased flow rate. You will need to calculate the flow rate to see if it will be over your filter's flow rating.
 Reply


?     Asked on 5/11/2017by Matthew Campbell

Hi there, I have a hi flo pump that needs a motor and a basket. The motor is a bn25. The wet end pump is a sd-15-1n1cc. Could I use this complete setup? Let me know. Thx , Matt
 Reply

A  Answered on 5/11/2017 by InyoPools Product Specialist Lennox H.

Hi, Matthew. The Hi-Flo 1.5 HP A/G Pump - PD11506 is the correct replacement for SD-15-1N1CC pump.
 Reply


?     Asked on 5/10/2017by Matthew Campbell

Hello there, I have a waterway hi flo pump that I need a new motor and basket for. The motor is a bn25. The wet end pump is a sd-15-1n11cc. Can I use this whole setup? The wet end pump discharges on the side not on the top. Let me know. Thx, Matt
 Reply

A  Answered on 5/11/2017 by InyoPools Product Specialist Lennox H.

Hi, Matthew. Based on the pump model (SD-15-1N11CC) you will need the Hi-Flo 1.5 Hp Above Ground Pump, 3' Cord - PD11506. The discharge on this pump can be rotated to support a side discharge.
 Reply


?     Asked on 4/9/2017by Marty Sabourin

Just opened the pool forthe summer but what could cause the pump to put out very low pressure (2psi). Normally puts out 10 to 15 psi
 Reply

A  Answered on 4/10/2017 by InyoPools Product Specialist Scott W.

The pipes make need to be blown, there maybe some build up. I recommend Purge made by Natural Chemistry. It is probably that or you need to change the seals in your pump.
 Reply


?     Asked on 7/24/2016by Elizabeth Raimundi

I have this pump but do not know if there is a high low swicth.
 Reply

A  Answered on 7/24/2016 by InyoPools Product Specialist Lennox H.

Hi Elizabeth, This pump is a single speed pump so it does not have a High/Low switch.
 Reply


?     Asked on 4/17/2016by Inyo Visitor

When my kreepy krauler got above water, sucked air, I turned the pump off and I'm an 83 yr old widow and don't know how to fill with water before turning pump back on.
 Reply

A  Answered on 4/19/2016 by InyoPools Product Specialist Lennox H.

Hi, You can view our How To: Prime a Pool Pump video for instructions or you can hire a pool company to resolve your issue.
 Reply


?     Asked on 3/6/2016by Rick

Is the picture shown a vertical discharge pump? Is it possible to order it with a horizontal discharge pump?
 Reply

A  Answered on 3/8/2016 by InyoPools Product Specialist Lennox H.

Hi Rick, This pump is not available with a horizontal discharge, however you can rotate the wet end so that it is horizontal.
 Reply


?     Asked on 10/24/2015by brian

will this be adequate for a 28 ft pool? thanks
 Reply

A  Answered on 10/26/2015 by InyoPools Product Specialist Hector F.

As far as the water turnover rate needed to circulate this pool, yes but you need to make sure that the gallons per minute rating on the pump is compatible with the gpm rating for the filter.
 Reply


?     Asked on 9/28/2015by Fabian JImenez

Is this pump good enough for a 24ft round pool or should i go with a 1 1/2 pump?
 Reply

A  Answered on 9/29/2015 by InyoPools Product Specialist Robert M.

Hello Fabian - The 1HP Dynamo pump would be sufficient for a 24' above ground pool.
 Reply


?     Asked on 1/28/2015by Brian Noren

What are the warranty terms on this pump?
 Reply

A  Answered on 1/28/2015 by InyoPools Product Specialist Alex V.

Brian, The pump has a 1 year manufacturer's warranty. You would typically contact them directly for any warranty issues.
 Reply


?     Asked on 8/7/2012by Guest

I have a JWPA5E7L-2A2, do you carry a replacement for this model pump?
 Reply

A  Answered on 8/7/2012 by InyoPools Product Specialist Patrick P.

The JWPA5E7L-2A2 has been discontinued by Sta-Rite, we show that this pump was a 1 HP above ground pool pump with a horizontal discharge. With this being said we would suggest the Waterway 1 HP pump listed on this page which has a discharge port which can be set to vertical or horizontal, this will allow for minimal plumbing changes on your end.
 Reply


Top
Difficulty

Est. Repair Time

1 to 2 hrs

Tools Needed

Nut Drivers, Pliers, Socket Set, Wrench Set

2     1

Old pump kept shutting off from the overload.

Written on 7/28/2020 by Guest

Disconnected power and shut off supply and return valves. Drained system. Disconnected plumbing from the pump. Unbolted pump from base. Pulled new pump from box. Had to mount strainer basket to pump.

Bolted down new pump to base. Connected supply and return plumbing. Opened valves and bled air from strainer basket. Closed strainer basket. Attached a ground wire to the external terminal on pump and ran it to my house ground rod. Plugged in power and turned pump on.

Bled the rest of the air through the high point in my system on top of Hayward canister filter. So far so good. Works great!
