$241.37

Qty:

By Pureline


Recommended Alternatives

Details

Top

Part # PL1153

Warranty 1 Year

Alternate Part #'s C48AB48A01, C48L2N131A7, C48L2N134A3, C48L2N134A4, C48L2N134A5, C48L2N134A9, C48l2n134b1, C48L2N134B3, C48L2N134B4, C48L2N134B5, UST1152

Product Description



Pureline 1.5 HP Up Rate Pool Pump Motor – PL1153

Replaces UST1152 | Round Flange 56J Frame
Aftermarket motor compatible with Hayward® & Jacuzzi® pumps

Perfect Replacement If Your Motor Is:

  • Humming, not starting

  • Overheating or leaking

  • Making loud noises

Key Features:

  • 1.5 HP, Single Speed

  • Round Flange 56J Frame

  • High-quality sealed ball bearings for quiet, long-lasting operation

  • 1-Year Manufacturer Warranty

Common Compatibility: (For Reference Only – Not OEM)

  • Hayward® Super Pump®

  • Hayward® Super II®

  • Hayward® Max-Flo®

  • Jacuzzi® Magnum®

DIY-Friendly:

  • Video installation guide available

  • Avg. install time: ~1 hour

  • Save on labor by installing it yourself

Don’t Forget:
Tune-Up Kit Recommended (sold separately)
Includes shaft seal, o-rings & gaskets — protects your investment and avoids leaks
⚠️ Using old seals can cause failure and void the motor warranty

⚠️ Important Notes:

  • NOT Title 20 compliant (California/New York)

  • Manufacturer names are used only for compatibility reference



California and New York Title 20 Compliant Option:

Disclaimer:

All manufacturers’ names, brand names, trademarks, images, symbols, descriptions, and part numbers are used herein for reference purposes only.

Product Specifications

Commonly Used On:
Hayward Max Flow, Hayward Super Pump, Hayward Super II, Hayward Northstar and Jacuzzi Magnum
Frame:
56J
HP:
1.5 HP
Service Factor:
1.0
Volts:
115/230 V
Amps:
17.8/8.9 amp
Total HP:
1.5 HP
Flange:
Round
Speed:
Single
Manufacturer:
Pureline
Top

?     Asked on 3/21/2023by Francis J Bisson

is this compatible with hst150 motor?
 Reply

A  Answered on 3/25/2023 by InyoPools Product Specialist Hector F.

Hello Francis, yes the PL1153 is compatible to replace the HST150. We also recommend replacing the seals and gaskets when replacing a pool pump motor. Here is our "Finding the Tune-Up Kit for Your Pool Pump" guide that should assist you with that.
 Reply


?     Asked on 5/22/2024by Dean Adams

would this take the place of a ust 1152
 Reply

A  Answered on 5/24/2024 by InyoPools Product Specialist Robert M.

Yes, the PL1153 will replace the UST1152.
 Reply


Top
Difficulty

Est. Repair Time

1 to 2 hrs

Tools Needed

Screwdriver, Nut Drivers, Pliers, Socket Set, Wrench Set

The wire connectors were not crimping right

Written on 6/3/2025 by Guest

Followed the INYO video as usual and it was right on. However, the wiring on the Pureline pump was different than the Hayward. It needed crimped clips to connect to the electric wire I tried three times to crimp the clips properly but failed. Lucky I had my own crimping clips that worked great for some reason
