Baracuda / Zodiac Manta InGround Parts

Baracuda / Zodiac Manta InGround Diagram

Click to zoom in

Diagram #	Part Title
1	OBSOLETE FLOAT BALL
2	OBSOLETE SPUR BALL
3	OBSOLETE BELLY WEIGHT
4	MANTA IG OUTER BODY TOP
5	MANTA IG OUTER BODY BOTTOM
6	APRON, (TURQUOISE) (W49855)
7	COMPRESSION RING
8	OBSOLETE INNER BODY
9	FOOT PAD (TURQUOISE)
10	INNER EXTENSION PIPE, THREADED
11	RETAINING RING, DIAPHRAGM
12	DIAPHRAGM
13	EXTENSION PIPE, OUTER With NUT
14	DEFLECTOR,WHEEL 12"(TURQUIOSE)
15	INGROUND SEAL
16	FLOWKEEPER VALVE
17	INGROUND VALVE CUFF (W63900)
18	POOL PULSE
19	45 DEG. ELBOW (W90146)
20	HOSE WEIGHT
21	4 1/2" CONNECTOR - AQUA
22	HOSE PROTECTOR, NATURAL

View Parts List
