Baracuda / Zodiac Pacer - After 2004 Parts

MODEL W83215 2004/2005

Baracuda / Zodiac Pacer - After 2004 Diagram

Click to zoom in

Diagram #	Part Title
1	FINNED DISC
2	FOOT PAD
3	INNER BODY
4	COMPRESSION RING
5	WEIGHTED SPUR
6	OUTER EXTENSION PIPE
7	"WHEEL DEFLECTOR, 12"""
8	DIAPHRAGM
9	RETAINING RING, DIAPHRAGM
10	INNER EXTENSION PIPE, THREADED
11	POOL PULSE
12	45 DEG. ELBOW (W90146)
13	INGROUND VALVE CUFF (W63900)
14	FLOWKEEPER VALVE
15	HOSE PROTECTOR, NATURAL
16	4 1/2" CONNECTOR - AQUA
17	HOSE WEIGHT
18	STANDARD HOSE KIT - 12X1 METER - AQUA

View Parts List

Diagram #	Part Title
1	FINNED DISC
2	FOOT PAD
3	INNER BODY
4	COMPRESSION RING
5	WEIGHTED SPUR
6	OUTER EXTENSION PIPE
7	"WHEEL DEFLECTOR, 12"""
8	DIAPHRAGM
9	RETAINING RING, DIAPHRAGM
10	INNER EXTENSION PIPE, THREADED
11	POOL PULSE
12	45 DEG. ELBOW (W90146)
13	INGROUND VALVE CUFF (W63900)
14	FLOWKEEPER VALVE
15	HOSE PROTECTOR, NATURAL
16	4 1/2" CONNECTOR - AQUA
17	HOSE WEIGHT
18	STANDARD HOSE KIT - 12X1 METER - AQUA
