20-018
|
BRUSH, RUBBER, MOLDED, 7.25"; 4 BRUSHES; (EA/1/1)
|
|
10-029
|
DRIVE TRACK, G TYPE, BLUE; (EA/2/2)
|
|
90-002
|
Replacement Fine Filter Bag for Aquabot
|
|
30-001
|
SCREW, S/S, PH-PN; (EA/4/4)
|
|
80-002
|
TIE, PANDUIT, 7.4"; (EA/4/4)
|
|
80-012
|
P CLIP, 11/16", S/S, 9 WIRE; (EA/2/2)
|
|
10-007
|
Outer Body, Ultramax Jr
|
|
30-006
|
SCREW, 8-18 .75", S/S, PH-FIL; (EA/4/4)
|
|
30-007
|
SCREW, #8 X 7/16", S/S, PH-PN; (EA/2/2)
|
|
30-013
|
SCREW - LOCK TAB -BODY ASS./DUMAX
|
|
10-014
|
BUSHING, .5 ID, NYLON, WHITE; (EA/4/4)
|
|
30-020
|
SCREW, #8 .6875", S/S, PH-PN; (Single)
|
|
30-021
|
SCREW, #8 .625", S/S, PH-PN; (EA/2/2)
|
|
30-022
|
SCREW- S/S- FILTER SCREEN
|
|
10-030
|
DRIVE BELT, TAN, SMALL; (Single)
|
|
30-034
|
SCREW, S/S, PH-PN, 10-32 x 2.108 (EA/8/8)
|
|
30-035
|
NUT, S/S, HEX LOCK M5; (EA/2/2)
|
|
10-037
|
ROLLER, SMALL, PLASTIC, WHITE; (EA/4/4)
|
|
10-038
|
SLEEVE ROLLER, STEPPED
|
|
30-038
|
WASHER, ACETYL, 1.5" OD X .5" ID X .125"T; (EA/2/2)
|
|
10-044
|
GROOVED PIN COVER; (EA/1/1)
|
|
10-046
|
FILTER SCREEN, SMALL, WHITE; (EA/1/1)
|
|
30-046
|
NUT, S/S, LOCK; (EA/1/1)
|
|
10-056
|
FILTER BAG CLIP, PLASTIC, LARGE, BLACK; (Single)
|
|
10-060
|
CAP PLUG, WHITE, 1.125"; (EA/1/1)
|
|
30-016
|
LOCK TAB, NATURAL; (EA/2/2)
|
|
10-064
|
VALVE FLAP, PVC, BLACK, LG BOTTOM LID; (EA/2/2)
|
|
30-058
|
RETAINER RING, .5",S/S, E STYLE; (EA/4/4)
|
|
30-060
|
WASHER, S/S, 5/32; (EA/2/2)
|
|
80-020
|
TIE, PLT PANDUIT, 6"; (EA/4/4)
|
|
80-022
|
TRANSMITTER, FCC, 3 BUTTON; (EA/1/1)
|
|
10-085
|
OUTLET TOP/BOTTOM -UMX/UMXJR
|
|
10-091
|
BUSHING, NYLON, BLACK; (EA/2/2)
|
|
10-107
|
SIDE PLATE, BLUE, BASIC; (EA/1/1)
|
|
70-013
|
CABLE, ASSY, 9C/120', 4-16/5-22 AWG, FLT, BLUE, 9PRF, 16A125; (EA/1/1)
|
|
15-007
|
HANDLE ASSY, BLUE, AUMXJR, W/BASIC BRACKET, COMPLT; (EA/1/1)
|
|
10-118
|
PULLEY ASSY, LARGE PULLEY W WASHERS; (EA/1/1)
|
|
20-015
|
WHEEL TUBE ASSY, 15", SPLIT, AUMXJR; (EA/1/1)
|
|
60-015
|
POWER SUPPLY, ASSY, US, 120/36V, 2 PRF, RC, ADMXDUO, ADMXDUOJR, UMX (EA/1/1)
|
|
95-003
|
ROPE ASSY, 12.5', 1 FLOAT, AUMXJR; (EA/1/1)
|
|
10-126
|
BOTTOM LID ASSY, LARGE, NATURAL, COMMERCIAL; (EA/1/1)
|
|
50-021
|
ORDER (S1A8034SK MASTER, 8B, AUMX, AUMXJR, 1-SKMS03, 1-SKMS02; (EA/1/1)
|
|
50-022
|
ORDER (S1A8038)SK DRIVE, 8B, SLAVE, AUMXJR, 1-SKMS02; (EA/1/1)
|
|
80-032
|
SK JUNCTION BOX, AUMXJR, 1-SKMS03, 1-SKMS02; (EA/1/1)
|
|
10-152
|
SK TRACK GUIDE, MOD G TRACK, 2 LEFT/2 RIGHT;(EA/1/1)
|
|
80-035
|
SK MOTOR INSTALL KIT 1; 1 (1617) 3.5", 1 (1619) 4.5", 2 (5474); (EA/1/1)
|
|
80-036
|
SK MOTOR INSTALL KIT 2; 1 (1614) 3.5"; (EA/1/1)
|
|
80-037
|
SK MOTOR INSTALL KIT 3; 1 (1611) 2", 1 (1633); (EA/1/1)
|
