PER THE MANUFACTURER: THIS ITEM IS NOT AVAILABLE FOR SALE ONLINE

By Sta-Rite


Details

Top

Part # P6EA6F206L

Manufacturer Code P6EA6F-206L

Alternate Part #'s PENP6EA6F-206L, STA-10-313

Product Description

Inyo Recommended Pumps

MAX-E-PRO PUMPS By Sta-Rite

SUPERIOR HYDRAULIC DESIGN MOVES MORE WATER, RESULTING IN LOWER ELECTRICAL COSTS

This new high efficiency, low maintenance pump is designed for maximum performance for the modern pool. Advanced state-of-the-art hydraulics means that Max-E-Pro delivers more water resulting in lower electrical costs. It will keep your pool crystal clear as well as run your automatic cleaner and any other hydraulic accessories around your pool. Not only is this pump energy efficient, it is ultra quiet. Special dampening in and around the pump’s base makes Max-E-Pro one of the quietest pumps in its class.



The extra large 6” trap collects more debris, allowing you to clean the trap less often. Our clear see-thru lid allows you to check for debris without removing the lid. The new Quick-Lock trap cover ring makes loosening or tightening the trap a cinch. Max-E-Pro is self-priming and produces enough suction to lift water 5-feet above pool level. Large 2” ports include external and internal threads to adapt to a variety of pipe sizes.

The Max-E-Pro is built to last, constructed of Sta-Rite’s glass reinforced resin that is corrosion-proof and can withstand many years of U.V. sunlight. This season, invest in the energy efficient, low-maintenance pump that really moves the water – Max-E-Pro by Sta-Rite. 110/230V UL Listed and NSF. Backed by a 1-Year Warranty.





Product Specs:

  • Voltage = 115/230
  • Max. Load Amps = 16.0/8.0
  • Horse Power = 1 1/2
  • Pipe Size = 2"

Click here for more Sta-Rite Pumps

Product Specifications

HP:
1 1/2 HP
Speed:
Single
Volts:
115/230 V
Amps:
16/8
Port Size:
2 in.
Service Factor:
1.1
Union Connectors:
Not included
Top

?     Asked on 7/4/2015by Inyo Visitor

What is the difference between Full Rate and Up Rate?
 Reply

A  Answered on 7/4/2015 by InyoPools Product Specialist Patrick P.

We have a good article here Explaining the Difference Between Full Rate & Up Rate Pool Pumps.
 Reply


?     Asked on 4/8/2016by Al

Is this pump self priming and how much lift? Is it built for in ground pools?
 Reply

A  Answered on 4/9/2016 by InyoPools Product Specialist Lennox H.

Hi Al, The Sta-Rite Max-E-Pro pumps are self-priming and is used for in-ground pools. You can reference the Performance Curves "E" for performance data.
 Reply


?     Asked on 6/22/2017by Michael Paul

I have a Sta-Rite Max-E-Glas II series P4EA,6F-187L 1.5 HP pump that may need to be replaced. It got flooded and is in the pool repair shop now. Is the P6EA6F206L a correct replacement if I need to buy a new pump? Thank you. MP
 Reply

A  Answered on 6/25/2017 by InyoPools Product Specialist Lennox H.

Hi, Michael. This Max E Pro Pump - P6EA6F206L can be used as a replacement for the Max E Glas II Pump - P4EA6F-187L.
 Reply


?     Asked on 4/1/2018by Inyo Visitor

What is the flow rate of the Sta-Rite P6EA6F206l in gallons per minute? I cant find this stat anywhere
 Reply

A  Answered on 4/2/2018 by InyoPools Product Specialist Lennox H.

Hi. To determine the flow rate, you will have to first calculate the Total Dynamic Head or Feet of Head of your pool. With that info you will then use the Max-E-Pro Performance Curve to determine the flow rate.
 Reply


?     Asked on 4/3/2020by Inyo Visitor

Have a pea5f-125l with 1 1/2 hp motor that needs replacing. Will this model be a good replacement. Is this a complete pump and motor arrangement?
 Reply

A  Answered on 4/3/2020 by InyoPools Product Specialist Patrick P.

Our reccomendation is this 1-1/2 HP Waterway Champion Pump as the Waterway Champion pump will be a drop-in replacement when using the adjustable base which is included with the pump. This means your plumbing from your Sta-Rite Max-E-Glas pea5f-125l will line up with the Waterway Champion meaning little to no re-plumbing.
 Reply


Top

Review Summary

 (Average 4.63  out of 5 stars)
8 Rating
5 star:

(5)
4 star:

(3)
3 star:

(0)
2 star:

(0)
1 star:

(0)
