$239.99

Qty:

By PureLine


Details

Top

Part # PL1507

Warranty 1 Year

Product Description

PureLine Pure Pro XL Pool Pool Pump

Same quality as Hayward®, Sta-Rite® and Pentair®!

The PureLine Pure Pro XL is a powerful above-ground pump featuring a corrosion proof construction that delivers years of reliable service. This Pure Pro XL is a high-performance pump that is quiet, efficient and all of this at an affordable price. The top discharge design fits most filters making installation a snap and its extra large clear lid allows for easy cleaning. Replace your old inefficient pump with this water moving dynamo.

Dual Speed Means Low Operational Costs - up to 70% less

This pump is a dual speed pump meaning that it has super low operational costs. Dual speed pumps have a switch that allows you to run the pump at a high speed of 1.5 HP or you can switch the pump to the low speed to operate at .39 HP. Normally you can run the pump at the low speed for your general filtration and when doing so this costs about 70% less than running at the high speed of 1.5 HP. The great thing is you have the high speed for things like vacuuming or if you get into a demanding algae situation.

California Title 20 Compliant

This pump is compliant with the California Title 20 energy efficiency laws.

Accessories

Click here for 1.5" Quick Disconnect Unions for the Pure Pro XL Pump

Click here for Hose Connectors 1.5"

Click here for Pool Pump Timer for the Pure Fro XL Pump

Click here for the Inground Pool Version of this Pump

Application

  • Above ground pool of all types (including in-floor cleaning systems, solar heating systems, water features or water garden)

Features

  • Strainer basket cover removes easily for cleaning
  • Includes 115V 6' Cord with 3 Prong Plug
  • Transparent strainer basket cover lets know when basket needs cleaning
  • All components molded of corrosion-proof reinforced thermoplastic for extra durability and long life
  • Drain plug for easy pump winterization

Dimensions

PureLine 1500 Dimensions

Pump Curve

Disclaimer:

All manufacturers’ names, brand names, trademarks, images, symbols, descriptions, and part numbers are used herein for reference purposes only.

Product Specifications

HP:
1.5 HP
Manufacturer:
Pureline
Pool / Spa Type:
Above Ground
Volts:
115 V
Speed:
Dual
Amps:
12.0/3.6 amp
Service Factor:
1.0
Total HP:
1.5 HP
Port Size:
1.5 in.
Pump Model:
Pure Pro XL
Installation:
Residential
Cord Type:
Standard 3 Prong
Cord Length:
6 ft.
Pool Type:
Above Ground
Top

?     Asked on 10/8/2013by Guest

How many hours per day should I run my pump?
 Reply

A  Answered on 10/8/2013 by InyoPools Product Specialist Patrick P.

There are many factors to consider; bather load, gallons of water, pump horsepower, type and size of filter just to name a few. A good guideline is 8-10 hours a day. On the cooler days and early and late season, you can cut the run time down to 4-6 hours because there is usually less swimmers and cooler water requires less chemicals. In peak season, when it is the hottest, raising the run time to 10-12 hours per day will help to keep the pool clean and circulating during it’s time of heaviest use.
 Reply


?     Asked on 7/5/2019by Inyo Visitor

Can this be changed to side discharge?
 Reply

A  Answered on 7/5/2019 by InyoPools Product Specialist Patrick P.

You can rotate the PL1507 to side discharge by following this Guide on How to Rotate the Discharge on Pure Pro XL to Horizontal
 Reply


?     Asked on 7/14/2019by Barry Ruter

HAD A MODEL 1502 WILL THIS WORK INSTEAD.LIKE DUAL SPEED
 Reply

A  Answered on 7/16/2019 by InyoPools Product Specialist Lennox H.

Hi, Barry. Yes, this PL1507 can be used as a replacement.
 Reply


?     Asked on 7/23/2019by Carol

Is this pump self priming?
 Reply

A  Answered on 7/23/2019 by InyoPools Product Specialist Hector F.

Above ground pool pumps are not self-priming as an above ground pool water level is higher than the pump which by gravity will feed water to the pump allowing it to prime.
 Reply


?     Asked on 7/23/2019by Tabatha

will this pump work for a 18×48 Coleman pool? if so how do I go about hooking it up with the hoses?
 Reply

A  Answered on 7/23/2019 by InyoPools Product Specialist Lennox H.

Hi, Tabatha. This pump will be too powerful if you want to use the original filter.
 Reply


Top
Difficulty

Est. Repair Time

1 to 2 hrs

Tools Needed

Screwdriver, Nut Drivers, Pliers, Socket Set, Drill, hacksaw

2     0

Bought the house and the pump was no good and had rubber hoses instead of pvc.

Written on 5/6/2021 by Guest

I ordered a new pump and went to Lowes and got 20ft of pvc pipe and several elbows, threaded connectors and shutoff valves. I looked at the old hose and cut/dry fit my pvc before glueing. Once glued I waited a few hours before turning the pump on. Works like a charm now.
