Pureline Diverter with Spider Gasket Compatible with Pentair 272512 Hi-Flow Six-Way Pool and Spa 1-1/2-Inch Multiport Valve - PL0742

$39.99

IN STOCK

Part # PL0742

By PureLine

  4.69 Average

Details

Top

Part # PL0742

Dimensions 5-3/4" W X 4-1/2" H

Alternate Part #'s 272512, 4600-2512, PAC0618968, 27-110-1450, PAC-061-8968, PEN272512

Product Description

Generic Replacement Top valve assembly for Pentair Top Mount 272512 valve

This is a Generic Replacement Top Valve for the Pentair 272531 Valve.  This valve is most commonly used on Pentair Tagelus, Pentair Sand Dollar, Pentair Meteor and Sta-Rite Crystal-Flo II sand filters.



Commonly Used On

HI-FLOW MODELS 26-1124, 26-1130, 26-2506, 272523

PRIMARILY USED ON PAC-FAB (PUREX/TRITON SYSTEMS) TAGELUS FILTERS



USED ON PAC FAB 26-2506,26-1130 TOP MOUNT GASKET NOT AVAILABLE SEPERATELY . 5-11/16"(ROTOR) 4 SPOKE GASKET ..... DIMENSIONS OUTSIDE DIAMETER: 5-5/16" (GASKET) CENTER HOLE INSIDE DIAMETER: 1-7/16" (GASKET) .. 1-1/8" (ROTOR) SPOKE THICKNESS: 1/8" (SIDE TO SIDE) OUTSIDE RING THICKNESS: 1/8" (SIDE TO SIDE) TOTAL HEIGHT: 4-3/4" (ROTOR)

Top

?     Asked on 3/14/2022by jay

Will this fit Pentair Multiport valve 272526.
 Reply

A  Answered on 3/15/2022 by InyoPools Product Specialist Rich N.

Hi Jay, the Replacement Valve Diverter w/ Spider Gasket for Pentair™ - PL0742 will be perfect for your Pentair - Pac Fab Top Mount 1 1/2" 26-2506 valve.
 Reply


?     Asked on 10/17/2021by Marlo Matoska

Is magic lube needed to install this part?
 Reply

A  Answered on 10/19/2021 by InyoPools Product Specialist Robert M.

No, Magic Lube is not needed to install this part.
 Reply


?     Asked on 8/20/2021by Inyo Visitor

I have a Pentair P/N 261185, will this fit?
 Reply

A  Answered on 8/20/2021 by InyoPools Product Specialist Robert M.

No, this is not the correct diverter for the 261185 valve. The correct diverter is part number 4600-1168
 Reply


?     Asked on 6/27/2020by Inyo Visitor

I need a spider gasket for pentair 272599 Thank you
 Reply

A  Answered on 10/23/2020 by InyoPools Product Specialist Hector F.

Hello, this is the correct part that includes the spider gasket as it is not sold separately for the model Pentair 272599  multiport valve.
 Reply


?     Asked on 6/5/2020by Randy Keener

Does this valve diverter w/spider gasket 272512 fit a Pentair 27-2599 6/98 - written on label on top, on side label is P/N 272526 VLV SD19/22 1.5" HiFLO? Thank you, Randy
 Reply

A  Answered on 12/2/2020 by InyoPools Product Specialist Hector F.

Hi Randy, yes this is the correct replacement valve diverter w/ spider gasket for your Pentair multiport valve model 272526. Here is a general guide that we put together called "How to Replace a Spider Gasket on a Multiport Valve" that may assist.
 Reply


?     Asked on 2/15/2020by Jason

Need a spider gasket for pics below

 Reply

A  Answered on 2/17/2020 by InyoPools Product Specialist Lennox H.

Hi, Jason. The gasket is not sold separately, it's only available as part of this Valve Diverter.
 Reply


?     Asked on 12/4/2019by thaddeus arnold

Can one order the spider gasket for #272523 or will I have to order the higher assembly diverter valve to get it ?
 Reply

A  Answered on 12/4/2019 by InyoPools Product Specialist Lennox H.

Hi, Thaddeus. Unfortunately, the gasket is NOT sold separately, you will have to purchase this Valve Diverter w/ Spider Gasket - 272512 or the Top Valve Assembly - 272531
 Reply


?     Asked on 4/25/2019by Kellea

Does this diverter assembly come with the O rings shown in the how to replace video?
 Reply

A  Answered on 5/5/2019 by InyoPools Product Specialist Lennox H.

Hi, Kellea. No other o-rings are included with this Diverter. Those parts are listed on the Pentair Hi-Flow 1-1/2" Parts Diagram page.
 Reply


?     Asked on 9/13/2017by Suki

will this fit 6 way vlv asy 272523? my serial number is 0518344050005G. label also has container id 11642666 site E. i have some pictures of the valve and what is broken. i can send them to you, if you can give me a email id. thanks.
 Reply

A  Answered on 9/13/2017 by InyoPools Product Specialist Patrick P.

Hi Suki, Yes this valve Diverter with Spider Gasket does work with the 272523 valve assembly.
 Reply


?     Asked on 6/24/2017by Inyo Visitor

What is the part number for the matching spring assembly for this part? Thanks.
 Reply

A  Answered on 6/27/2017 by InyoPools Product Specialist Lennox H.

Hi, You can use p/n 272400 if your valve was manufactured after May 1, 1992 or p/n 272535 if your valve is older.
 Reply


?     Asked on 6/14/2017by Jim Clancy

I plan to order a new Diverter, Valve W/gasket {272512}. The video showed using Loctite 401, 403, or 416. It also mentioned aSuper weatherstrip Adheasive. Do I need these two products for the seat of the gasket? And do you sell them? Thank you for your help. Jim
 Reply

A  Answered on 6/15/2017 by InyoPools Product Specialist Patrick P.

Hi Jim, you don't need all of those items just one of the 3. We carry this Super Weatherstrip Adhesive that we suggest. Please note that the 272512 comes with the gasket already glued in so you will not need the adhesive.
 Reply


?     Asked on 7/27/2016by Inyo Visitor

How do you replace the diverter, valve w/gasket assy.
 Reply

A  Answered on 7/28/2016 by InyoPools Product Specialist Alan M.

Here are instructions on How To Replace a Pool Multiport Valve Spring. The instructions focus on the spring, but the diverter valve is included in the replacement instructions.
 Reply


?     Asked on 6/23/2016by jim

I need the gasket for part # 272526, it is leaking to the discharge side?
 Reply

A  Answered on 6/30/2016 by InyoPools Product Specialist Lennox H.

Hi Jim, The gasket is not sold separately, this Valve Diverter w/ Gasket is the correct replacement part.
 Reply
