$284.38

Qty:

By Custom Molded Products


Details

Top

Part # SP0715X62

Alternate Part #'s 27517-204-000, SM2-HPX62, 06-263, HPPSP0715X62, SP715X62

Product Description

This is an After-Market replacement Valve by CMP for the Hayward Vari-Flo XL multiport control valve. This valve is made of quality materials and engineered for maximum flow at lower pressure drops will be the choice in multiport valves. It will retrofit any filter that has an SP071113 valve that needs replacement and upgrading. Does not include clamp and o-ring.

This valve features an easy-to-use lever-action handle that lets you "dial" up to six valve/filter functions: filter, backwash, waste, rinse, closed or recirculate. Complete with an integral sight glass that lets you see when the backwashing cycle is completed.

Control Valve Functions

  • Filter - For normal filtering and regular vacuuming
  • Backwash - For cleaning filter sand bed of accumulated debris
  • Rinse - Use after completing backwash cycle to ensure all dirty water is rinsed out of the filter to waste
  • Waste - By-passes the filter for draining or lowering pool water level and for vacuuming heavy debris directly to waste line.
  • Recirculate - Water is recirculated through the valve by-passing the filter
  • Closed - Shuts off the flow from the pump to the filter
  • Winter - For winterizing (SP0714T only)
  • 1 year warranty

Product Specifications

Plumbing Size:
2 in.
Model:
Hayward Pro Series Side Mount Sand Filters
Valve Type:
Multiport
Valve Location:
Side Mount
Top

?     Asked on 1/31/2012by Guest

I need parts for my filter valve. When I look at the filter parts breakdown, it gives me different choices. How do I know which one is the one I need?
 Reply

A  Answered on 1/31/2012 by InyoPools Product Specialist Patrick P.

In order to locate the correct parts we will need to know the model number of the filter valve. Two identical filters can have two different valves. Typically the valve model will be located on the label of the valve. If there is no model number on the valve, you can try to see if there are any part numbers on the valve itself. Once you've located you valve model you can check out our >Filter Valve Parts.
 Reply


?     Asked on 6/1/2015by Vicki

I'm looking for a replacement part for my Hayward s240 filter. The part I need is multiportvalue value it is 2 inch
 Reply

A  Answered on 6/1/2015 by InyoPools Product Specialist Andy O.

Vicki- The recommended multiport valve for the S240 would be the SP0715X32.
 Reply


?     Asked on 7/7/2015by Robert Fernandez

Will this side mount valve fit my 2" leaky valve? I have a Pentair part number 140243 sand filter for my in ground pool.? Valve model # is SM-20-3
 Reply

A  Answered on 7/8/2015 by InyoPools Product Specialist Hector F.

Negative. This is a Pentair model filter hence it needing their design valves. On your filter's parts diagram here on key 39 are the listed valves that are compatible with your filter.
 Reply


?     Asked on 7/21/2015by Inyo Visitor

I have a Hayward valve model number sp71032. What is the replacement valve model number?
 Reply

A  Answered on 7/21/2015 by InyoPools Product Specialist Robert M.

Part number SPX0710X32 (4800-25) is the correct replacement valve for the SP71032.
 Reply


?     Asked on 6/6/2016by Nigel

Hello, Do you sell the sight glass only
 Reply

A  Answered on 6/6/2016 by InyoPools Product Specialist Patrick P.

Hi Nigel, yes the SPX0710MA is the Sight Glass Only for this valve.
 Reply
