Plug w/ O-ring 1-1/2" - SPX1022C - Black - 552622



Part # 4700A

  4.89 Average



Part # 4700A

Manufacturer Code 552622

Dimensions 1.25" L x 2.19" W x 2.19" D

Alternate Part #'s 004309, 25543-000-000, 552417, 552622, 59200250, 801, CP-100-08, CP10008, HAY2511503, PAC0519569, SP1022C, SPX1022C, WFITPLUG, 17-605-1000, 25543-004-000, APC1022C, HAY-251-1503, HAYSP1022C

Product Description

Plug w/ O-ring 1-1/2" - SPX1022C

Note: Now shipping in Black


?     Asked on 10/30/2022by Steve

Will this plug fit my Pac-Fab Nautilus NS-48 D. E. Filter? The original part number is 19-5820 + 19-2323 o-ring. Thank you.

A  Answered on 10/30/2022 by InyoPools Product Specialist Hector F.

Hello Steve, the correct drain plug for the Pac Fab Nautilus filter model NS48 is part number 4600-5829. I have also emailed you an estimate that you can convert to an order if you would like. This item is in stock.

?     Asked on 1/2/2022by Del Albright

Will this fit a Hayward older model DE-2400-Z-10 ?

A  Answered on 1/3/2022 by InyoPools Product Specialist Craig C.

Hello Del.  The Plug with O-Ring 1 1/2" - SPX1022C will fit the Hayward Micro Clear DE Filter DE-2400-Z-10.   Plug w/ O-ring 1-1/2" - SPX1022C   Attached please find an exploded parts diagram for the Hayward  Micro Clear DE Filter.  Please note item Key 23.  Hayward Micro Clear D.E.

?     Asked on 4/2/2020by jim

Can you tell me how long the threaded portion of this plug is?

A  Answered on 11/11/2020 by InyoPools Product Specialist Megan C.

I see we have the length of the plug at 1.25", I do not have the listing for the threaded length only.

?     Asked on 7/21/2019by Michael Bonanno

Can this plug be used to winterize return jets after removing eyeballs?

A  Answered on 7/21/2019 by InyoPools Product Specialist Lennox H.

Hi, Michael. This plug can be used if the eyeball wall fitting or jet body is 1-1/2" FPT.

?     Asked on 6/5/2018by Kimberly Shaw

Will this fit my sand filter? The only label I can find says Ultra rate hi rate sand filter by poolco industries.

A  Answered on 6/5/2018 by InyoPools Product Specialist Lennox H.

Hi, Kimberly. This Plug w/ O-ring - SP1022C will fit the PoolCo Ultra Clear sand filters.

?     Asked on 8/1/2017by Stefan

Is the thread on this standard NPT ?

A  Answered on 8/2/2017 by InyoPools Product Specialist Alex V.

Stefan, Yes, this is a standard 1.5" male thread.

?     Asked on 6/26/2017by RUSSELL


A  Answered on 6/26/2017 by InyoPools Product Specialist Lennox H.

Russell. This Plug w/ O-ring will not fit the CL460 filter, you'll need the Jandy Drain Cap Assy - R0523000.

?     Asked on 11/6/2016by

How long does this take to ship.

A  Answered on 11/7/2016 by InyoPools Product Specialist Alan M.

Standard ground shipping is 3-5 business days.

?     Asked on 5/31/2016by Inyo Visitor

is this the plug that covers the discharge spigot? it's threaded, and we never did see the plug in place. it's a Hayward Variflow SPS0710x32. and it never leaked before (4 years) but now it leaks constantly

A  Answered on 6/5/2016 by InyoPools Product Specialist Lennox H.

Hi, This Plus can be used with the SP0710X32 valve, the o-ring is bad but the o-ring is just as much as the plug which comes with the o-ring.

?     Asked on 5/25/2016by Inyo Visitor

I have an older Cartridge filter, Blue Haven 450/550. Will this filter plug fit it? Thanks!

A  Answered on 5/25/2016 by InyoPools Product Specialist Patrick P.

Yes this plug does fit the Blue Haven 450/550 Smart Filter.

?     Asked on 8/9/2015by Inyo Visitor

does this plug fit model DE2420LA?

A  Answered on 8/11/2015 by InyoPools Product Specialist Hector F.

If you are referring to the Hayward Pro Grid Perm-A-Glass DE2420 model then yes this is the correct plug.

?     Asked on 6/1/2015by Frank

Do u have longer threaded drain plug for C3025...because mine keeps popping off and its new

A  Answered on 6/5/2015 by InyoPools Product Specialist Lennox H.

Frank,There is not a drain plug with longer threads that can fit the Hayward C3025. If the Drain Plug w/O-ring (SP1022C) is new and it's popping out of the filter tank then the threads on the tank may be worn preventing the drain plug from fitting properly.


Est. Repair Time

Less than 1 hr

Tools Needed


The old plug cracked

Written on 5/30/2021 by Guest

Removed the old plug by unscrewing it and washed out the bottom of the filter tank with a water hose. Made sure no debris was in the threads of the tank and screwed in the new plug.
