By Maytronics
Part # 3295-219
Manufacturer Code 5020011
Alternate Part #'s 5020011, 87-111-1174, DL5020011, MAY5020011
Amphenol Socket For Power Supply - 5020011
I need a part for my Dolphin pool cleaner but I don't see it on the parts breakdown. Is there still a chance you may still have it?
Reply
The manufacturer which is Maytronics, does not offer all parts for sale. If you don't see a part on the breakdown you can give us a call. For parts that they do not consider "DIY (do it yourself), you will need to contact them and send in the cleaner for repair.
Reply
its there a pin out diagram to help me wire the connector which wire gords to pin 1 2 3 4
Reply
Jerry, Unfortunately, we do not have a print out. I would recommend taking a picture of how the plug is wired before removing them.
Reply
Less than 1 hr
Screwdriver, WD-40, and you could use a very small Allen key.
Socket was disconnected. Couldn't find any wiring diagram for how to re-connect. I saw another thread on the INYOPools site that suggests taking a picture of the wires before installing. Well, mine was disconnected, so a little late for that. I did web search for 'fix plug on dolphin pool cleaner and checked out a few youtube videos. This proved semi-useful:
https://www.youtube.com/watch?v=9zW9-WbSXrQ
But after viewing the video, my 'problem' was that my Dolphin only had two wires, a white and black (no red). I think my model is around 10 years old. So I took a chance and rewired the white wire to the #2 pin, and the black to the #3 pin. It worked. Now, the other problem I had before I started the wiring, was that I did not have an Allen key small enough to fit the set screw, and on top of that, the set screw was rusted and wouldn’t turn. So first I sprayed it with WD-40. Let it sit for about 5 minutes. I was able to turn it by using a very small blade flat head screwdriver.
Be careful not to take the set screw out too far! I did my work over a white spackle bucket, so if the set screw fell out, it would fall into the bucket.
Hope this helps someone!
