Century 1.5 HP Square Flange 56Y Dual Speed Full Rate Motor - B2983

$339.99

IN STOCK
FREE SHIPPING

Part # 5282-5

By Century Motors

  5 Average

Details

Top

Part # 5282-5

Warranty 1 Year

Manufacturer Code B2983

Dimensions 6.5" L x 14" W x 9" D

Alternate Part #'s 193990, 7-193990-07, B2983, 35-126-1254, AOSB2983, MGT-60-2983

Product Description

E-PLUS SQUARE FLANGE 56Y FRAME 2 SPEED CATALOG # B2983 ..... HORSEPOWER LABEL HORSEPOWER: 1.5-.19 SERVICE FACTOR: 1.47 ..... ELECTRICAL VOLTAGE: 230 VOLTS SINGLE PHASE AMP DRAW: 10.0/1.6 AT 230 VOLTS ..... SHIPPING WEIGHT: 36.94 LBS

NOTE THIS MOTOR IS SHIPPED LESS HI-LO SWITCH. YOU MAY PURCHASE THE HI-LO SWITCH SEPARATELY BY ORDERING PART # 2512558-001.

Motor Dimensions Motor Dimensions
Motor Image Motor Image

Product Specifications

Motor Name:
1.5 HP B983 & B2983 Replacement Pool Motor
HP:
1.5/ .19 HP
Speed:
Dual
RPM:
3450/1725 RPM
Volts:
230 V
Amps:
10.0/1.6 amp
Service Factor:
1.47
Total HP:
2.21 HP
Frame:
56Y
Stock #:
B983 or B2983
Shaft:
Threaded
Overload Protector:
Auto
Dimension Letter:
C
Dimensions:
13.9 in.
Commonly Used On:
Pentair WhisperFlo
Certification:
California Title 20 Compliant
Notes:
California Title 20 Compliant
Top

?     Asked on 6/21/2021 by Austin Wood

I am looking for the 1.88hp version of this pump motor.

 Reply

A  Answered on 6/21/2021 by InyoPools Product Specialist Patrick P.

Hi Austin you will require this 1.88 Total HP Dual Speed Motor for the motor included in your photo. You will also need a Hayward Tri-Star Seal Kit when you replace your motor. We put together this Video on How to Replace a Pool Pump Motor which you may find helpful when you tackle this project.
 Reply


?     Asked on 6/2/2021 by Greg Falls

will this motor replace the ao smith in the photo. Also attaching a picture of the heyward pump, i think you recommend a seal replacement as well

 Reply

A  Answered on 6/2/2021 by InyoPools Product Specialist Patrick P.

Hi Greg, Instead of this motor we would suggest this 5112-271 Hayward TriStar Replacement Motor as a direct replacement to the motor in your photo. You will also require this Hayward TriStar Seal Kit
 Reply


?     Asked on 5/8/2021 by Lon

Is this the correct replacement for the Pentair Superflo Dual speed motor? Do you stock a seal/gasket kit for the superflo pump?

 Reply

A  Answered on 5/9/2021 by InyoPools Product Specialist Patrick P.

Yes we carry this replacement motor and you will require this B2982 Dual Speed Motor You will also need a Pentair Super Flo Seal Kit when you replace your motor. We put together this Video on How to Replace a Pool Pump Motor which you may find helpful when you tackle this project.
 Reply


?     Asked on 4/29/2021 by Jorge

What gaskets and seals do I need if I’m replacing my current motor with the B2983 motor? See photo. Thanks.

 Reply

A  Answered on 4/30/2021 by InyoPools Product Specialist Danny R.

Jorge,Thank you for the pictures.  For a complete parts breakdown of your pool pump please click on the following link... Jandy Stealth SHPF & SHPM Series Pump (2008-Current). The replacement gaskets and seals for your pool pump are listed on this parts breakdown.
 Reply


?     Asked on 4/29/2021 by Jorge

Does the B2983 replace the 7-193994-06 motor?

 Reply

A  Answered on 4/30/2021 by InyoPools Product Specialist Danny R.

Yes this pool pump motor will work as a replacement for the 193994.
 Reply


?     Asked on 4/29/2021 by Phillip Modglin

Is the B2983 a suitable replacement for whisperflo wfe 6 1.5 motor?

 Reply

A  Answered on 4/30/2021 by InyoPools Product Specialist Robert M.

Yes, the B2983 could be used as a 2-speed motor option for the Whisperflo WFE-6. The motor does not come with a hi/lo switch. If you don't currently have a control system that can switch the speeds, you can order the toggle switch separately. The part number is 2512558-001.
 Reply


?     Asked on 4/23/2021 by

Hello... does this pump replace the 7-K56AA23A04-05. Thank you.
 Reply

A  Answered on 4/23/2021 by InyoPools Product Specialist Craig C.

Hello.  Yes. This is a replacement motor Century 1.5 HP Square Flange 56Y Dual Speed Full Rate Motor - B2983for the 7-K56AA23A04-05.
 Reply


?     Asked on 10/9/2020 by Chris Burgess

The motor you say I need is 56j frame I have a 56y frame. I don't understand why the difference.
 Reply

A  Answered on 10/27/2020 by InyoPools Product Specialist Joe S.

Hello Chris, attached is a blog What Does My Pump Motor’s Frame (FR) Rating Mean?
 Reply


?     Asked on 9/23/2020 by Albert Perez

Hello will this work for SPX3215Z2BE

 Reply

A  Answered on 10/30/2020 by InyoPools Product Specialist Hector F.

Hi Albert, yes this is the correct replacement motor for your motor model SPX3215Z2BE. When replacing a pool motor we do suggest a Seal Kit. Could you send us a few photos of your pump so we can suggest the proper seal kit? If so then please take a wide shot of the complete pump to include the pipes going in and out of the pump. To supply photos simply click the reply link below and upload your photos. Once we get those photos we can make the proper recommendation for your seal kit.
 Reply


?     Asked on 9/16/2020 by Charles Little

Is this a cross for the century 0-193990-07
 Reply

A  Answered on 9/18/2020 by InyoPools Product Specialist Matt S.

Yes, the correct replacement motor is the Century 1.5 HP Square Flange 56Y Dual Speed Full Rate Motor - B2983.
 Reply


?     Asked on 8/11/2020 by nom

Hi if i'm trying to switch my single speed Century 1.5 HP Square Flange 56Y to a dual speed motor. is this one correct? also anything else i'd need to change to upgrade? thanks

 Reply

A  Answered on 8/12/2020 by InyoPools Product Specialist Lennox H.

Hi, Nom. Yes, this B2983 is the correct dual speed replacement motor.
 Reply

  • Commented on 9/26/2020 by Product Owner

    i think i also need the high/low switch to convert from single to dual. is there a seal kit for this model? can you link to that please.
     Reply

    • Commented on 10/22/2020 by InyoPools Product Specialist Hector F.

      Hi Norman, the toggle switch is part number 2512558-001 which is currently a special order however you can also use Intermatic dual speed timer part number T106R. And in order to locate the seals and gaskets, we will need ti to know the model name or number of the front pump housing wet end that the motor attaches to. Or you can provide an image of that pump housing here as well.
       Reply


?     Asked on 3/3/2020 by Ipe Kalathoor

I need to buy this replacement motor. changing it for the first time, for Jandy 2 speed stealth pro series stealth pump. The pump has become noisy. Can you recommend the parts I need to buy along with this motor?. The label is attached. I know that I should buy a new seal. The pump seems to be expensive. Any discounts will be appreciated. Thanks Ipe

 Reply

A  Answered on 3/3/2020 by InyoPools Product Specialist Lennox H.

Hi, Ipe. You will also need to replace the Pump Shaft Seal - R0445500 or R0479400, Diffuser O-Ring - R0622000, and Backplate O-Ring - R0446300. Other parts are listed on the Jandy Stealth SHPF & SHPM Series Pump (2008-Current) Parts Diagram page.
 Reply

  • Commented on 3/3/2020 by Product Owner

    can you also confirm the motor is correct replacement B 2983? Any cheaper appropriate and efficient 2 speed motors?
     Reply

    • Commented on 3/4/2020 by InyoPools Product Specialist Lennox H.

      Ipe, The B2983 motor is the correct replacement. There is not a cheaper option available.
       Reply

  • Commented on 3/3/2020 by Product Owner

    Would either pump shaft seal mentioned above will work.
     Reply

    • Commented on 3/4/2020 by InyoPools Product Specialist Lennox H.

      Ipe, No, only one shaft seal will work based on the age of your pump or if the impeller is original.
       Reply

      • Commented on 3/4/2020 by Product Owner

        Impeller should be original. Pump was installed in 2015. Which one is the right seal then?
         Reply

        • Commented on 3/5/2020 by InyoPools Product Specialist Lennox H.

          Ipe, The Pump Shaft Seal - R0479400
           Reply

          • Commented on 3/6/2020 by Product Owner

            Thank you for the recommendations. I bought all the parts.
             Reply

            • Commented on 3/14/2020 by Product Owner

              I got all the parts. The motor seal and washers fit perfect. Confused with wiring because the leads are not marked the same way. I have green blue black and red wires. My system has Hi and Lo toggle switch for 2 speeds. Attaching old motor wired and and new motor empty leads. Could you guide me where black blue and red goes. Thank you

               Reply

              • Commented on 3/18/2020 by InyoPools Product Specialist Lennox H.

                Ipe, The motor will be wired L1 = Red, L2 = Blue, A= Black, Green = Ground Screw.
                 Reply

                • Commented on 3/21/2020 by Product Owner

                  Just FYI, the connection you said was wrong, my connection was correct. When I attempted yours, the breaker went off. Luckily didn’t burn the pump. I reversed the connection as showed in the picture. Blue to L1, Red to L2 , black to A and Green to ground. I am attaching a link to my YouTube video which could help similar customers. Thank you for your help. https://youtu.be/EENSQgw5DVE
                   Reply


?     Asked on 9/16/2019 by rey grecia

im looking for a replacement of pool motor , our motor model # sp32151zber or model # t63cxdz-1653
 Reply

A  Answered on 9/17/2019 by InyoPools Product Specialist Michelle B.

Hello, I can look into this for you. Can you please send a picture of the motor label?
 Reply


?     Asked on 8/13/2019 by Dennis Ragland

Looking for a replacement century motor. Have Century SP3210Z2ME, also has this number 7-K56AA23A04 It's a dual speed pool pump motor. Which one will replace
 Reply

A  Answered on 8/13/2019 by InyoPools Product Specialist Lennox H.

Hi, Dennis. This B2983 or the SPX3210Z2MER motors are your replacement options.
 Reply


?     Asked on 6/8/2019 by Guest

I live in California that now requires a VSP. Other than a seal kit, does the switch to a VSP require additional components?
 Reply

A  Answered on 6/8/2019 by InyoPools Product Specialist Lennox H.

Hi, Guest. A VSP requires 230 volt electrical and some requires an external timer. Otherwise, no additional components are required.
 Reply


?     Asked on 3/31/2019 by Dan

Hi, I'm replacing a Pentair WFE-6 /011514, and see you recommend this pump motor as a replacement. I have solar panels on my roof (two story home), will this be enough on low speed to circulate through the panels? Also, all my relays on my controller are used by other options (spa air pump, pool lights, spa lights, etc.) do you have any options for using the low speed in this situation? Thanks.
 Reply

A  Answered on 4/6/2019 by InyoPools Product Specialist Lennox H.

Hi, Dan. Operating the pump on low speed will not provide enough water flow to operate the solar. I will need to know the model of your controller to find out your options.
 Reply


?     Asked on 3/7/2019 by Ivan

If I order this motor B2983, how long will it take for me to receive?
 Reply

A  Answered on 3/8/2019 by InyoPools Product Specialist Lennox H.

Hi, Ivan. This motor will arrive on the third business day after the ship date if the ship to address is within the contiguous USA.
 Reply


?     Asked on 1/14/2019 by Bill Main

Is this the correct replacement motor for the Century 7-193990-07 connected to a Jandy SHPM2.0-2 pump?

 Reply

A  Answered on 1/14/2019 by InyoPools Product Specialist Michelle B.

Hello, You can use the B2842 Single Speed Motor or the B2983 Dual Speed Motor as replacements for Part No. 7-193990-07.
 Reply


?     Asked on 8/31/2018 by Keith

Is this motor a alternative to the hayward Spx3215z2ber Tristar?
 Reply

A  Answered on 8/31/2018 by InyoPools Product Specialist Lennox H.

Hi, Keith. This Century B2983 motor can be used as an alternate replacement for the Hayward SPX3215Z2BER motor.
 Reply


?     Asked on 4/27/2018 by

How much is actually saved in electrical costs going from a 2-speed to a variable speed. Trying to determine the payback equation.
 Reply

A  Answered on 4/27/2018 by InyoPools Product Specialist Lennox H.

Hi. They're several calculation tools that you can use depending on the manufacturer. If you would like to just change the motor with the Century V-Green VS Motor, you can use the V-Green Calculator
 Reply


?     Asked on 4/7/2016 by David

Is this the correct replacement motor for a 2008 pentair PMP WFDS-6 230v 1 1/2HP, p/n 011522?
 Reply

A  Answered on 4/8/2016 by InyoPools Product Specialist Lennox H.

Hi David, This B2983 motor is the correct replacement motor for the WFDS-6 pump. I would also recommend that the get the Pentair/Purex Whisperflo Tune Up Kit p/n GOKIT32 or GOKIT32SALT.
 Reply


?     Asked on 1/19/2012 by Guest

I'm trying to replace the motor on my pool pump but all these numbers and abbreviations on the motor label are really confusing me. What do they mean?
 Reply

A  Answered on 1/19/2012 by InyoPools Product Specialist Patrick P.

Replacing a pool pump motor is not as difficult as it seems. You can try looking here. If you need help figuring out what the information on your label means. If you are still having difficulty figuring it out you can call us at our toll free number or you can send us a photo of your motor label here.
 Reply


?     Asked on 1/11/2012 by Guest

What is Service Factor?
 Reply

A  Answered on 1/11/2012 by InyoPools Product Specialist Patrick P.

Service Factor(SF) is a multiplier that when multiplied by the horsepower of the motor indicates the total permissible horsepower loading that may be carried when the motor is operating at rated voltage and frequency. The most important thing to remember when replacing a motor is that the replacement motor's horsepower times its service factor must be equal to or greater than the original motor's horsepower times its service factor. The Service Factor rating can be found on the motor label. See Step 4 of our How to Read a Pool Motor Label guide.
 Reply


Top
Difficulty

Est. Repair Time

1 to 2 hrs

Tools Needed

Screwdriver, Pliers, Digital multimeter

3     0

Noisy Pump Motor

Written on 6/15/2018 by Guest

After reaching out to INYO Pool customer service to ensure that I knew which model to purchase and consulting the INYO Pool website to download the appropriate wiring diagram, I took the plunge and purchase a replacement motor with confidence that I could do the work myself. Armed with a Phillips screwdriver, a pair of wire cutters/strippers and a multimeter to confirm the power was shutoff (safety first), I was able to swap out my old, noisy motor with an OEM replacement in under two hours time. Everything fit perfectly and the new motor sounds great... and I did it all myself for less than half of what the pros quoted me! Thank you INYO Pool Products!
