Model # PL1502

Warranty 1 Year

Dimensions 23" x 10-1/2"

Alternate Part #'s 6579, PO12730, RELBC2730

Product Description

PureLine Pure Pro XL Pool Pool Pump

Same quality as Hayward®, Sta-Rite® and Pentair®!

The PureLine Pure Pro XL is a powerful above-ground pump featuring a corrosion proof construction that delivers years of reliable service. This Pure Pro XL is a high performance pump that is quiet, efficient and all of this at an affordable price. The top discharge design fits most filters making installation a snap and its extra large clear lid allows for easy cleaning. Replace your old inefficient pump with this water moving dynamo.

Click here for 1.5" Quick Disconnect Unions for the Pure Pro XL Pump

Click here for Hose Connectors 1.5"

Click here for Pool Pump Timer for the Pure Fro XL Pump

Click here for the Inground Pool Version of this Pump

Application

  • Above ground pool of all types (including in-floor cleaning systems, solar heating systems, water features or water garden)

Features

  • Strainer basket cover removes easily for cleaning
  • Includes 115V 6' Cord with 3 Prong Plug
  • Transparent strainer basket cover lets know when basket needs cleaning
  • All components molded of corrosion-proof reinforced thermoplastic for extra durability and long life
  • Drain plug for easy pump winterization

Dimensions

PureLine 1500 Dimensions

Pump Curve

Disclaimer:

All manufacturers’ names, brand names, trademarks, images, symbols, descriptions, and part numbers are used herein for reference purposes only.

Product Specifications

HP:
1.5 HP
Manufacturer:
Pureline
Pool / Spa Type:
Above Ground
Volts:
115 V
Speed:
Single
Amps:
12.0 amp
Service Factor:
1.0
Total HP:
1.5 HP
Port Size:
1.5 in.
Pump Model:
Pure Pro XL
Installation:
Residential
Cord Type:
Standard 3 Prong
Cord Length:
6 ft.
Discharge Location:
Vertical
Pool Type:
Above Ground
Top

?     Asked on 10/8/2013by Guest

How many hours per day should I run my pump?
 Reply

A  Answered on 10/8/2013 by InyoPools Product Specialist Patrick P.

There are many factors to consider; bather load, gallons of water, pump horsepower, type and size of filter just to name a few. A good guideline is 8-10 hours a day. On the cooler days and early and late season, you can cut the run time down to 4-6 hours because there is usually less swimmers and cooler water requires less chemicals. In peak season, when it is the hottest, raising the run time to 10-12 hours per day will help to keep the pool clean and circulating during it’s time of heaviest use.
 Reply


?     Asked on 8/15/2016by steve

Does pump hav an on & off switch?
 Reply

A  Answered on 8/19/2016 by InyoPools Product Specialist Lennox H.

Hi Steve, This pump does not have an On/Off switch.
 Reply


?     Asked on 12/10/2016by A. R. Diehl

can this pump be changed to horizonal instead of vertical connection to filter?
 Reply

A  Answered on 12/12/2016 by InyoPools Product Specialist Lennox H.

Hi. The discharge on this pump can be rotated to support a horizontal discharge application.
 Reply


?     Asked on 1/16/2017by Inyo Visitor

how many gal is the flow on pureline pool pump pl1502
 Reply

A  Answered on 1/17/2017 by InyoPools Product Specialist Lennox H.

Hi, The flow rate is based on the Feet of Head of the pool. You can view the pump performance curve located in the Product Description of this pump.
 Reply


?     Asked on 3/26/2017by mark young

Can this motor be wired for 220V?
 Reply

A  Answered on 3/26/2017 by InyoPools Product Specialist Patrick P.

Hi Mark, No this motor cannot be wired 220V. I would suggest the PL1601 1.5 HP Pump if you need the motor to be wired 220V.
 Reply


Top
Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Screwdriver, Wrench Set, Adjustable Wrench

Old pump would not run

Written on 6/16/2023 by Guest

Replaced old Hayward pump with Pureline pump. Installation was a simple plug and play. Removed old outlet and inlet fittings and installed in new pump. New pump fit perfectly on old mounting bracket. Plugged into power outlet and we were running!

Were these instructions helpful?


Difficulty

Est. Repair Time

1 to 2 hrs

Tools Needed

Screwdriver, metal clamp to hold hose

I had sand at the bottom of my pool

Written on 6/25/2022 by Guest

I first got the water clear by shocking and balancing the pool. I then needed to get sand and debris from the floor of the pool. I ordered a 1.5 HP above ground pool from Inyopools. It was the most reasonable I found. I hooked up my vacuum to the suction side of the pump and hooked up another hose to the outlet port of the pump. Next you prime the pump by adding water to the basket area of the pump. Turn the pump on and you can now vacuum the pool floor without clogging up your filter with all the debris and sand on the bottom of your pool. You may have to prime the pump a few times to get it suctioning strong but it goes pretty fast once it is at full suction. Just keep in mind you will have some water loss in your pool but its worth it because it cleans your pool of all the debris fast.

Were these instructions helpful?


Difficulty

Est. Repair Time

1 to 2 hrs

Tools Needed

Screwdriver

Inadequate pool pump - Needed new one.

Written on 9/16/2021 by Guest

The existing pump was installed by another gentleman, and it came with the filter he brought a few years ago. This year the pump was not keeping up and since I couldn't locate the previous repairman I removed the pump and took it to a repair shop. They took a couple of weeks to get back to me but by then I had installed my new INYOPOOL pump, It has truly worked like a charm

Were these instructions helpful?


Difficulty

Est. Repair Time

1 to 2 hrs

Tools Needed

Screwdriver, Adjustable Wrench

1     0

Our old Hayward was noisy and leaking

Written on 7/12/2021 by Guest

We replaced old hayward 1.5 hp with inyo’s house brand that was over 100.00 cheaper. It performs flawlessly and is way quieter than the hayward. Everything line up perfectly fittings were the same size and in same locations so installation was easy.

Were these instructions helpful?


Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Pliers, Channel locks

1     0

Our old pump motor went out

Written on 8/26/2019 by Guest

We received the package, and it was assembled. All we had to do was connect our swimming pool hoses. It was super easy!

Were these instructions helpful?


Difficulty

Est. Repair Time

1 to 2 hrs

Tools Needed

Screwdriver, Wrench Set

0     1

Repalcement pump

Written on 8/22/2019 by Tom M.

Lowest cost. Easy install. Runs super quiet. Does the job.

Were these instructions helpful?


Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Monkey wrench

1     0

Old pump stopped working

Written on 8/12/2019 by Guest

Turn off power on the old pump. Turn intake in return off. Removed original pumps intake and return. Replace with new pump exact fittings as before. Tightened all fittings. Turn intake and return back on. Power up the new pump good to go.

Were these instructions helpful?


Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Nut Drivers

Replace old pump with new pump.

Written on 7/8/2019 by Guest

Turn off old pump and unplug. Place pool filter valve in closed position. Remove hoses leading to and from pump. Reconnect hoses to new pump. Place filter valve in filter position. Restart pump.

Were these instructions helpful?


Difficulty

Est. Repair Time

2 to 4 hrs

Tools Needed

Screwdriver, Nut Drivers, Pliers, Adjustable Wrench

0     1

Pump went out

Written on 7/7/2019 by Guest

Inyo pools had the right pump at the right price, will be doing more business with them soon

Were these instructions helpful?


Difficulty

Est. Repair Time

1 to 2 hrs

Tools Needed

Screwdriver, Pliers

Motor had burned up

Written on 7/2/2019 by Guest

It was a matter of cutting 2 pipe. I still cannot believe the incredible savings.

Were these instructions helpful?


Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Screwdriver, Adjustable Wrench

Old pump quit

Written on 6/29/2019 by Guest

Replaced with new pump. Working great.

Were these instructions helpful?


Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Screwdriver, Pliers, Socket Set

Old pump motor froze up

Written on 6/14/2019 by Guest

Removed the 2 hoses from old pump removed mounting bolts. Removed the old pump.

Placed the new pump on the mount put in mounting bolts. Replaced the 2 hoses primed the pump and plugged it in. Works great.

Were these instructions helpful?


Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Nut Drivers

Old Pump Making Terrible Noise

Written on 4/29/2019 by Guest

Replaced it with the motor I bought from Inyo Pools.

Were these instructions helpful?


Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Screwdriver

4     0

My old pump just gave out

Written on 4/23/2018 by Pool Dawg

Shut off all water connections.
Disconnected all pipe clamps.
Removed all pipe connections.
Unscrewed the base of the pump.
Removed old pump.
Screwed down base on new pump.
Teflon tape on all pipe connections.
Reconnected all pipe clamps.
Turned back on all water connections.
Turned pump on.
Really easy!

Were these instructions helpful?


Difficulty

Est. Repair Time

Less than 1 hr

Tools Needed

Screwdriver, Pliers, Adjustable Wrench

3     0

Old pool pump died

Written on 3/28/2017 by Guest

Tested old pump and it had no power, would not run
I went on line, found s similar sized unit and ordered it.
When it arrived I tested it first, then hooked it up to the pool systems and it ran fine.

Were these instructions helpful?
