By Hayward Pool Products


Details

Top

Part # W3SP3010X15AZ

Warranty 1 Year

Alternate Part #'s HAYW3SP3010X15AZ, HAY-10-1023, HPPW3SP3010X15AZ

Product Description

Inyo Recommended Pumps

Specs:

  • Voltage = 115/230
  • Pipe Size = 2"

Applications

  • In-ground pools of all types and sizes (including in-floor cleaning systems, solar heating systems, water features)
  • In-ground spas or in-ground pool/spa combinations
  • Fountains

Hayward Super 2 Pump Features

  • Self-priming (suction lift up to 8' above water level)
  • Easy thread design makes strainer cover removal easy
  • Lexan® see-thru strainer cover lets you see when basket needs cleaning
  • 180 cubic inch basket has extra leaf-holding capacity. Load-extender ribbing ensures free flowing operation
  • All components molded of corrosion-proof PermaGlass XL™ for extra durability and long life
  • Heavy-duty, high performance motor for quieter, cooler operation
  • Service-ease design gives simple access to all internal parts
  • Includes Pump Lid removal tool

Hayward Super 2 Pump Warranty

1 Year Housing
1 Year Motor and Parts

Hayward Super 2 Performance Data

  Pump Output (GPM) vs. Total Resistance To Flow (Feet of Head)
Model No. Max Rated Model No. Full Rated 40 ft 50 ft 60 ft 70 ft 80 ft 90 ft
SP3005X7AZ   47 38 26 12 - -
SP3007X10AZ SP3007EECA 63 55 46 32 - -
SP3010X15AZ SP3010EEAZ 89 80 69 56 34 -
SP3015X20AZ SP3015EEAZ 112 102 90 75 56 -
SP3020X25AZ SP3020EEAZ 132 118 103 86 62 -
SP3025X30AZ SP3025EEAZ 157 146 133 118 102 80
  SP303063AZ 157 146 133 118 102 80





Motor Performance / Amp Draw - Standard Pump Vs. Energy Efficient

<stro

Product Specifications

HP:
1.5 HP
Manufacturer:
Hayward
Pool / Spa Type:
Inground
Volts:
115/230 V
Speed:
Single
Amps:
18.6/9.3 amp
Service Factor:
1
Total HP:
1.5 HP
Port Size:
2 in.
Pump Model:
Super II
Installation:
Residential
Top

?     Asked on 4/26/2015by Dennis

Can the pump be disassembled to check if something is lodged in the motor. Recently, replaced capacitor pump started fine then stoped.
 Reply

A  Answered on 4/27/2015 by InyoPools Product Specialist Patrick P.

Hi Dennis, Yes the pump can be disassembled we have a great How to Guide and Video showing how to replace a pool motor and this goes into the disassembly of the pump. I think you will find this helpful.
 Reply


?     Asked on 9/14/2015by Bill Criss

Need a SP 3010x 15az Hayward Super II Pump - but not the electric motor. Do you sell just the pump ? Thank
 Reply

A  Answered on 9/15/2015 by InyoPools Product Specialist Joe S.

Hello Bill, there is no kit to order just the wet end of this unit. you would need to order from the Hayward Super II Parts page
 Reply


?     Asked on 8/22/2016by Dan Hammond

Went to turn pump back on after being off for a few hours. It sounded funny and then saw smoke from the motor. Quickly turned it off. Its SP3010X15AZ Hayward SUper II for an inground fiberglass Salt pool. Before I call a Pool Service nearby (Rome GA), just wondered...is it possibly just the motor, or the whole pump ?? I've been looking online for this item number and see pumps and motor, or both as a package?? Dan
 Reply

A  Answered on 8/22/2016 by InyoPools Product Specialist Alan M.

Hello Dan, sounds like the motor fried. You can replace just the motor with the Century 1.5 HP Round Flange Up Rate Motor (C48L2N134) Formerly A.O. Smith - UST1152. I would also recommend replacing the seals when ever you change the motor with the Tune Up Kit Hayward Super II - GOKIT2.
 Reply


?     Asked on 8/23/2016by Dan Hammond

Just got your response from Alan M. But do I need a SALT version of the Tune Up Kit or are they all the same?
 Reply

A  Answered on 8/23/2016 by InyoPools Product Specialist Scott W.

The saltwater shaft seal is going to be the only difference in that kit, which is a heavy duty, less corrosive shaft seal than the regular shaft seal. If you have a saltwater pool you should definitely get the saltwater kit, if it's chlorine you'll be fine with the regular kit.
 Reply


?     Asked on 12/22/2017by Cesar

Is this a direct drop in replacement for the Hayward RS1000?
 Reply

A  Answered on 12/22/2017 by InyoPools Product Specialist Megan C.

The Super II Pump 1 1/2 HP Single Speed - SP3010X15AZ is comparable in total horsepower to the RS1000. The main difference is the intake and discharge ports, the RS1000 offers threaded 1.5" inside and 2" outside. The SP3010X15AZ has 2" threads on the inside of the intake and discharge and measures a little over 25"' in length. Please refer to our How To Replace a Pool Pump for detailed instructions.
 Reply


Top
Difficulty

Est. Repair Time

1 to 2 hrs

Tools Needed

Screwdriver, Pliers, Adjustable Wrench

3     0

Old system died

Written on 6/22/2018 by Guest

had to cut my old system free because when the installed it they didn't put any couplings. This was the hardest part of the install. Removed the old system and reconnect everythings exactly as I had removed it from the old system. No problems at all.
